5120-01-601-5163
Box Wrench
5120016015163 016015163 A-A-1346 27-268
A nonadjustable wrench having a box wrenching feature on one or both ends. Excludes WRENCH, OPEN END BOX; and WRENCH, BOX AND OPEN END, COMBINATION. View more Box Wrench
May 2023
7
Marketplace 5120-01-601-5163
Request a Quotation from participating marketplace vendors
Related Documents 5120-01-601-5163 1+ Documents (More...)
BUY NE Updated Every Day 27-268 RQST NE Updated Every Day 5120-01-601-5163 RQST NE Updated Every
Day 5120-01-601-5163 RQST Updated Every Day 5120-01-601-5163 RQST NE Related Documents 5120-01-601-5163
Restrictions 5120-01-601-5163
5120-01-601-5163 is a Box Wrench that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-601-5163
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-601-5163
- US Army (A192)
- Effective Date:
- 1 Sep 2014
- Supplementary Receivers:
- AZ
- NASA (G751)
- Effective Date:
- 1 Jun 2013
- US Marine Corps (MC14)
- Effective Date:
- 1 Jun 2013
- Hungary (WH01)
- Effective Date:
- 1 Jan 2012
Approved Sources 5120-01-601-5163
- Part Number
- Manufacturer
- Status
- A-A-1346
- Manufacturer
- 58536 - Federal Commercial Item Description (Active)
- Incomplete Standard
- Incomplete Standard
- 27-268
- 636D0 - Apex Tool Group, Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 27-268
- 08292 - Easco Hand Tools Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 27-268
- 03914 - Armstrong Bros Tool Co (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-01-601-5163
- Characteristic
- Specifications
- FIIG
- Specifications
- A527Y0
- Material [MATT]
- Steel Overall
- Overall Length [ABHP]
- 7.870 Inches Nominal
- Special Features [FEAT]
- Satin Finish
- Wrenching Surface Shape [CRWY]
- 12 Point Both Ends Internal
- Wrenching Surface Size [AJBR]
- 0.563 Inches Nominal First End
- Wrenching Surface Size [AJBR]
- 0.625 Inches Nominal Second End
- Specification/Standard Data [ZZZK]
- 81348-Asme A-A-1346A Professional/Industrial Association Standard
- Style Designator [STYL]
- Half-Moon Double Head
- Surface Treatment [SFTT]
- Chromium Overall
Management Data 5120-01-601-5163
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 2
- Non-Critical Repair Part
- Echelon Management:
- 02
- Operational Test:
- No Special Procedures
- Physical Category:
- 1
- Bin
Similar Supply Items to 5120-01-601-5163
Freight Information 5120-01-601-5163
5120-01-601-5163 has freight characteristics managed by Hungary.. 5120-01-601-5163 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
