5120-01-598-3115
Combination Box And Open End Wrench
5120015983115 015983115 AS955 TY3CL1STB 456720010001 52-208 AS955
A nonadjustable wrench having a box wrenching feature on one end and an open end wrenching feature on the other end. Excludes WRENCH, BOX and WRENCH, OPEN END. View more Combination Box And Open End Wrench
May 2023
11
Marketplace 5120-01-598-3115
Request a Quotation from participating marketplace vendors
Related Documents 5120-01-598-3115 5+ Documents (More...)
/fsg-51/fsc-5120/us 5120-01-598-3115 Combination Box And Open End Wrench AS955 TY3CL1STB45672001000152
having a box wrenching feature on one AS955 TY3CL1STB M13CWKS M13CW https//www.nsnlookup.com /fsg-51
AS955AS955 TY3CL1STBM17CWKSM17CWRM17CW AS955 TY3CL1STB 00942869000 42869 9-42869 A nonadjustable wrench
https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-398-9355 Combination Box And Open End Wrench,AS955
AS955AS955 TY3CL1STBM13CWKSM13CWM13CWR AS955 TY3CL1STB B107.6 TY1 B107.9M B107.100 B107.6 A nonadjustable
AS955 TY3CL1STB M17CWKS M17CWR M17CW A nonadjustable wrench having a box wrenching feature on one end
AS955 TY3CL1STB M17CWKS M17CWR M17CW A nonadjustable wrench having a box wrenching feature on one end
-208AS955 A nonadjustable wrench having a box wrenching feature on one AS955 TY3CL1STB M13CWKS M13CW
AS955 TY3CL1STB M17CWKS M17CWR M17CW A nonadjustable wrench having a box wrenching feature on one end
AS955AS955 TY3CL1STBM17CWKSM17CWRM17CW AS955 TY3CL1STB 00942869000 42869 9-42869 A nonadjustable wrench
Restrictions 5120-01-598-3115
5120-01-598-3115 is a Combination Box And Open End Wrench that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-598-3115
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-598-3115
- US Army (A192)
- Effective Date:
- 1 Apr 2015
- Supplementary Receivers:
- AZ
- NASA (G751)
- Effective Date:
- 1 Jun 2013
- US Marine Corps (MC14)
- Effective Date:
- 1 Jun 2013
- Hungary (WH01)
- Effective Date:
- 1 Jul 2011
- Australia (ZA01)
- Effective Date:
- 1 Apr 2013
Approved Sources 5120-01-598-3115
- Part Number
- Manufacturer
- Status
- AS955
- Manufacturer
- 0U583 - Sae International (Active)
- Incomplete Reference
- Incomplete Reference
- AS955 TY3CL1STB
- 80244 - General Services Administration (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 52-208
- 636D0 - Apex Tool Group, Llc (Active)
- Secondary Buy
- Secondary Buy
- 456720010001
- 0000V - Ncb Hungary (Honvedsegi Egyseges (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 52-208
- 08292 - Easco Hand Tools Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- AS955
- 81343 - Society Of Automotive Engineers Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 52-208
- 03914 - Armstrong Bros Tool Co (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-01-598-3115
- Characteristic
- Specifications
- FIIG
- Specifications
- A527Y0
- Material [MATT]
- Steel Overall
- Surface Treatment [SFTT]
- Chromium Overall
- Style Designator [STYL]
- Offset
- Overall Length [ABHP]
- 127.0 Millimeters Nominal
- Head Angle [CRCS]
- 15.0 Degrees Nominal
- Wrenching End Offset Angle [CSPX]
- 15.0 Degrees Nominal
- Wrenching Surface Size [AJBR]
- 8.0 Millimeters Nominal Both Ends
- Wrenching Surface Shape [CRWY]
- Oval First End Internal
- Wrenching Surface Shape [CRWY]
- 12 Point Second End Internal
- Features Provided [CBBL]
- Full Polish
Similar Supply Items to 5120-01-598-3115
Freight Information 5120-01-598-3115
5120-01-598-3115 has freight characteristics managed by Hungary.. 5120-01-598-3115 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
