5120-01-589-9827
Open End Wrench
5120015899827 015899827 J3130 1Q433 3130
A nonadjustable wrench having an open end wrenching feature on one or both ends. Excludes WRENCH, OPEN END BOX; WRENCH, LINEMAN'S; and WRENCH, BOX AND OPEN END, COMBINATION. View more Open End Wrench
May 2023
7
Marketplace 5120-01-589-9827
Request a Quotation from participating marketplace vendors
Related Documents 5120-01-589-9827 3+ Documents (More...)
Photo 1/4 5120-01-589-9827 Photo 2/4 5120-01-589-9827 Photo 3/4 NSN 5120-01-589-9827 (Identification
Quotation Updated Every Day J3130 RQST NE Updated Every Day 3130 RQST NE Updated Every Day 1Q433 RQST
/fsg-59/fsc-5930/us 5930-01-341-6894 Rotary Switch 5930013416894013416894 6541C122-15-16433-2W015-1Q433
Open End Wrench 5120015899827 015899827 Every Day 3130 RQST NE Updated Every Day 1Q433 RQST https
Restrictions 5120-01-589-9827
5120-01-589-9827 is a Open End Wrench that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-589-9827
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-589-9827
- Canada (ZC01)
- Effective Date:
- 1 Nov 2014
- France (ZF01)
- Effective Date:
- 1 Nov 2010
Approved Sources 5120-01-589-9827
- Part Number
- Manufacturer
- Status
- J3130
- Manufacturer
- 1CV05 - The Stanley Works (Active)
- Primary Buy
- Primary Buy
- 1Q433
- 25795 - W.W. Grainger, Inc. (Active)
- Secondary Buy
- Secondary Buy
- J3130
- Z19N0 - The Trustee For Henchman Unit Trust (Active)
- Secondary Buy
- Secondary Buy
- 3130
- 1CV05 - The Stanley Works (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- J3130
- ZAE87 - Henchman Products Pty Ltd (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-01-589-9827
- Characteristic
- Specifications
- FIIG
- Specifications
- A527Y0
- Material [MATT]
- Steel Overall
- Surface Treatment [SFTT]
- Chromium Overall
- Style Designator [STYL]
- Double Head
- Overall Length [ABHP]
- 8.750 Inches Nominal
- Large End Head Thickness [AJAU]
- 0.328 Inches Nominal
- Small End Head Thickness [AJAV]
- 0.328 Inches Nominal
- Small End Head Angle [CTHK]
- 15.0 Degrees Nominal
- Large End Head Angle [CWGT]
- 60.0 Degrees Nominal
- Wrenching Surface Size [AJBR]
- 0.938 Inches Nominal Both Ends
- Wrenching Surface Shape [CRWY]
- Oval Both Ends Internal
- Features Provided [CBBL]
- Full Polish
Similar Supply Items to 5120-01-589-9827
Freight Information 5120-01-589-9827
5120-01-589-9827 has freight characteristics.. 5120-01-589-9827 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
