5120-01-580-7876
Socket Wrench Socket
5120015807876 015807876 AS955 AS955 TY1CL1STA 39-130
An item having an internal drive at one end made to fit into the external drive end of a socket wrench handle, torque wrench, or power driven tool. The opposite end consists of various internal wrench shapes such as hexagon or square. It may include an integral universal joint. View more Socket Wrench Socket
May 2023
11
Marketplace 5120-01-580-7876
Request a Quotation from participating marketplace vendors
Related Documents 5120-01-580-7876 5+ Documents (More...)
AS955 SOCKET,SOCKET WRENCH 1 EA NS Request Quotation Subscribe to View Vendor Details... 5120-01-580-
www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-651-2947 Socket Wrench Socket 5120016512947 016512947 AS955
https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-580-7876 Socket Wrench Socket 5120015807876 015807876
AS955 TY1CL1STA 39-130 An item having an internal drive at one end made to fit into the external drive
SOCKET,SOCKET WRENCH 1 EA NS Request Quotation Updated Every Day 5120-01-348-9133 RQST NE Updated AS955
www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-348-9090 Socket Wrench Socket 5120013489090 013489090 AS955
www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-348-9259 Socket Wrench Socket 5120013489259 013489259 AS955
www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-348-9298 Socket Wrench Socket 5120013489298 013489298 AS955
to fit into the external An item having an internal drive at one end made to fit into the external AS955
www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-348-9301 Socket Wrench Socket 5120013489301 013489301 AS955
Restrictions 5120-01-580-7876
5120-01-580-7876 is a Socket Wrench Socket that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-580-7876
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-580-7876
- US Army (A192)
- Effective Date:
- 1 Sep 2012
- Supplementary Receivers:
- AZ
- NASA (G751)
- Effective Date:
- 1 Sep 2012
- Canada (ZC01)
- Effective Date:
- 1 Oct 2013
- Denmark (ZS01)
- Effective Date:
- 1 Dec 2009
Approved Sources 5120-01-580-7876
- Part Number
- Manufacturer
- Status
- AS955
- Manufacturer
- 0U583 - Sae International (Active)
- Incomplete Reference
- Incomplete Reference
- AS955 TY1CL1STA
- 80244 - General Services Administration (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 39-130
- 636D0 - Apex Tool Group, Llc (Active)
- Secondary Buy
- Secondary Buy
- 39-130
- 03914 - Armstrong Bros Tool Co (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- AS955
- 81343 - Society Of Automotive Engineers Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 39-130
- 08292 - Easco Hand Tools Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-01-580-7876
- Characteristic
- Specifications
- FIIG
- Specifications
- A102A0
- Drive End Outside Diameter [AHMK]
- 39.1 Millimeters Nominal
- Drive End Shape [CTCT]
- Square Single End Internal
- Drive Surface Size [ATNC]
- 0.500 Inches Nominal Single End
- Features Provided [CBBL]
- Manual Tool
- Material [MATT]
- Steel Overall
- Nondefinitive Spec/Std Data [ZZZT]
- 1 Type And 1 Class And A Style
- Overall Length [ABHP]
- 42.5 Millimeters Nominal
- Wrenching End Opening Depth [AJAP]
- 22.9 Millimeters Nominal
- Wrenching End Outside Diameter [AHMJ]
- 39.1 Millimeters Nominal
- Wrenching Surface Shape [CRWY]
- 12 Point Single End Internal
- Wrenching Surface Size [AJBR]
- 30.0 Millimeters Nominal Single End
- Specification/Standard Data [ZZZK]
- 81343-Sae As955 Professional/Industrial Association Standard
- Style Designator [STYL]
- Internal-Internal
- Surface Treatment [SFTT]
- Chromium Overall
NATO Stock Numbers Related to 5120-01-580-7876
Freight Information 5120-01-580-7876
5120-01-580-7876 has freight characteristics.. 5120-01-580-7876 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
