5120-01-579-1012
Socket Wrench Socket
5120015791012 015791012 AS954 AS954 TY1CL1STB B107.1 12-338 B107.1 TY1CL2
An item having an internal drive at one end made to fit into the external drive end of a socket wrench handle, torque wrench, or power driven tool. The opposite end consists of various internal wrench shapes such as hexagon or square. It may include an integral universal joint. View more Socket Wrench Socket
June 2023
16
Marketplace 5120-01-579-1012
Request a Quotation from participating marketplace vendors
Related Documents 5120-01-579-1012 5+ Documents (More...)
B107.1 TY1CL2B107.1 An item having an internal drive at one end made to fit into AD86 B107.1 TY1CL2
/fsc-5120/us 5120-01-430-2979 Socket Wrench Socket 5120014302979 014302979 AS954 TY1CL1STB 40832 B107.1
TY1CL1STB 1AF85 J4716LT B107.1 4716LT B107.1 TY1CL2 An item having an internal drive at one end https
Socket Wrench Socket 5120015791012 015791012 AS954 TY1CL1STBB107.1 12-338 B107.1 TY1CL2 An item
B107.1 TY1CL2 An item having an internal drive at one end made to fit GSTMD8 B107.1 AD86 B107.1 TY1CL2
Socket Wrench Socket 5120015791012 015791012 AS954 TY1CL1STBB107.1 12-338 B107.1 TY1CL2 An item
AD86 B107.1 TY1CL2 An item having an internal drive at CL1STB CL1STB https drive B107.1 TY1CL2 having
at one end made B107.1 TY1CL2 having AS954 TY1CL1STB40824 B107.1B107.1 https //www.nsnlookup.com /fsg
fsg-51/fsc-5120/us 5120-01-430-3025 Socket Wrench Socket 5120014303025 014303025 AS954 TY1CL1STB 40824
TY1CL2 having B107.1AD86B107.1 TY1CL2 An item having an internal drive at one end made B107.1 TY1CL2
Restrictions 5120-01-579-1012
5120-01-579-1012 is a Socket Wrench Socket that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-579-1012
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-579-1012
- US Army (A192)
- Effective Date:
- 1 Nov 2014
- Supplementary Receivers:
- AZBF
- NASA (G751)
- Effective Date:
- 1 Nov 2014
- US Navy (N9QG)
- Effective Date:
- 1 Jun 2015
- Supplementary Collaborators:
- GG
- Denmark (ZS01)
- Effective Date:
- 1 Oct 2009
Approved Sources 5120-01-579-1012
- Part Number
- Manufacturer
- Status
- AS954
- Manufacturer
- 0U583 - Sae International (Active)
- Incomplete Reference
- Incomplete Reference
- AS954 TY1CL1STB
- 80244 - General Services Administration (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- B107.1
- 05047 - The American Society Of Mechanical (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 12-338
- 636D0 - Apex Tool Group, Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- B107.1 TY1CL2
- 80244 - General Services Administration (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 12-338
- 08292 - Easco Hand Tools Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 12-338
- 03914 - Armstrong Bros Tool Co (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- AS954
- 81343 - Society Of Automotive Engineers Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-01-579-1012
- Characteristic
- Specifications
- FIIG
- Specifications
- A102A0
- Drive End Outside Diameter [AHMK]
- 1.563 Inches Nominal
- Drive Surface Size [ATNC]
- 0.500 Inches Nominal Single End
- Drive End Shape [CTCT]
- Square Single End Internal
- Features Provided [CBBL]
- Manual Tool
- Material [MATT]
- Steel Overall
- Nondefinitive Spec/Std Data [ZZZT]
- 1 Type And 1 Class And B Style
- Overall Length [ABHP]
- 3.235 Inches Nominal
- Wrenching Surface Size [AJBR]
- 1.188 Inches Nominal Single End
- Wrenching End Opening Depth [AJAP]
- 0.844 Inches Nominal
- Wrenching End Outside Diameter [AHMJ]
- 1.563 Inches Nominal
- Wrenching Surface Shape [CRWY]
- 12 Point Single End Internal
- Specification/Standard Data [ZZZK]
- 81343-Sae As954 Professional/Industrial Association Standard
- Style Designator [STYL]
- Internal-Internal
- Surface Treatment [SFTT]
- Chromium Overall
Management Data 5120-01-579-1012
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9Q
NATO Stock Numbers Related to 5120-01-579-1012
Freight Information 5120-01-579-1012
5120-01-579-1012 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186620. A Sub NMFC of Z. It has a NMFC Description of TOOLS, NOI HAND OTHER THAN POWER. 5120-01-579-1012 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5120-01-579-1012 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5120-01-579-1012 is not classified as a special type of cargo when transported by water. 5120-01-579-1012 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
