5120-01-524-8948
Torque Screwdriver
5120015248948 015248948 151SM
A manual tool for tightening vairous fasteners to a precise torque value. Consists of a handle and drive to accommodate female square drive sockets, screwdriver bits, and other types of wrenching adapters. Torque value may be manually set and adjusted by user of may be provided as preset for production line use. A signaling device is generally provided to indicate when set torque value is reached. Handle is spun in-line with axis of fastener rotation to apply torque. For items with handles that are swung at right angle to axis of fastener rotation to apply torque, see WRENCH, TORQUE. View more Torque Screwdriver
May 2023
7
Marketplace 5120-01-524-8948
Request a Quotation from participating marketplace vendors
Restrictions 5120-01-524-8948
5120-01-524-8948 is a Torque Screwdriver that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-524-8948
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-524-8948
- NASA (G751)
- Effective Date:
- 1 Dec 2005
- US Navy (N9QG)
- Effective Date:
- 1 Dec 2005
- Supplementary Collaborators:
- GT
- Spain (YB01)
- Effective Date:
- 1 Dec 2006
- Australia (ZA01)
- Effective Date:
- 1 Oct 2004
- Republic of Korea (ZH01)
- Effective Date:
- 1 Oct 2012
Approved Sources 5120-01-524-8948
- Part Number
- Manufacturer
- Status
- 151SM
- Manufacturer
- 55719 - Idsc Holdings Llc (Active)
- Primary Buy
- Primary Buy
Datasheet 5120-01-524-8948
- Characteristic
- Specifications
- FIIG
- Specifications
- A530H0
- Drive End Shape [CTCT]
- Hexagon Single End External
- Drive Surface Size [ATNC]
- 0.250 Inches Nominal Single End
- Overall Length [ABHP]
- 4.500 Inches Nominal
- Special Features [FEAT]
- Micro-Adjustable; Positive Locking Pull Down Adjustment Knob; Triobular Comfort Grip; Window Scale
- Torque Scale Graduation [AJCH]
- 0.20 Inch-Pounds
- Torque Capacity [AJCG]
- 3.0 Inch-Pounds Minimum And 15.0 Inch-Pounds Maximum
Management Data 5120-01-524-8948
Navy
- Cognizance:
- 9Q
NATO Stock Numbers Related to 5120-01-524-8948
Freight Information 5120-01-524-8948
5120-01-524-8948 has freight characteristics managed by Australia.. 5120-01-524-8948 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
