5120-01-503-2077
Box Wrench
5120015032077 015032077 27-469
A nonadjustable wrench having a box wrenching feature on one or both ends. Excludes WRENCH, OPEN END BOX; and WRENCH, BOX AND OPEN END, COMBINATION. View more Box Wrench
May 2023
6
Marketplace 5120-01-503-2077
Request a Quotation from participating marketplace vendors
Related Documents 5120-01-503-2077 1+ Documents (More...)
WRENCH,BOX 10 EA NS Request Quotation Updated Every Day 27-469 RQST NE Updated Every Day 5120-01-503
-01-503-2077 Box Wrench 5120015032077 015032077,27-469 Photo 1/3 5120-01-503-2077 Photo 2/3 NSN 5120-
Restrictions 5120-01-503-2077
5120-01-503-2077 is a Box Wrench that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-503-2077
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-503-2077
- Canada (ZC01)
- Effective Date:
- 1 Dec 2002
Approved Sources 5120-01-503-2077
- Part Number
- Manufacturer
- Status
- 27-469
- Manufacturer
- 636D0 - Apex Tool Group, Llc (Active)
- Primary Buy
- Primary Buy
- 27-469
- 08292 - Easco Hand Tools Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 27-469
- 03914 - Armstrong Bros Tool Co (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-01-503-2077
- Characteristic
- Specifications
- FIIG
- Specifications
- A527Y0
- Material [MATT]
- Steel Overall
- Surface Treatment [SFTT]
- Chromium Overall
- Style Designator [STYL]
- Deep Angular Offset Double Head
- Overall Length [ABHP]
- 17.000 Inches Nominal
- Large End Outside Diameter [AHMG]
- 2.000 Inches Nominal
- Small End Outside Diameter [AHMH]
- 1.656 Inches Nominal
- Large End Head Thickness [AJAU]
- 0.750 Inches Nominal
- Small End Head Thickness [AJAV]
- 0.718 Inches Nominal
- Wrenching End Offset Angle [CSPX]
- 45.0 Degrees Nominal
- Wrenching Surface Size [AJBR]
- 1.062 Inches Nominal First End
- Wrenching Surface Size [AJBR]
- 1.250 Inches Nominal Second End
- Wrenching Surface Shape [CRWY]
- 12 Point Both Ends Internal
Similar Supply Items to 5120-01-503-2077
Freight Information 5120-01-503-2077
5120-01-503-2077 has freight characteristics.. 5120-01-503-2077 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
