5120-01-434-9256
C Clamp
5120014349256 014349256 78-000
A clamping device in the shape of the letter C having a screw with or without a swivel button at the contact end, and a thumbscrew, T-handle, or square-end drive. Excludes CLAMP, LOOP. View more C Clamp
May 2023
11
Marketplace 5120-01-434-9256
Request a Quotation from participating marketplace vendors
Related Documents 5120-01-434-9256 1+ Documents (More...)
/fsg-51/fsc-5120/us
C Clamp 5120014349256 014349256,78-000 CLAMP,C 10 EA NS Request Quotation Updated Every Day 78-000 RQST
NE Updated Every Day 5120-01-434-9256 C Clamp 5120014349256 014349256,78-000 CLAMP,C 10 EA NS Request
Restrictions 5120-01-434-9256
5120-01-434-9256 is a C Clamp that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-434-9256
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-434-9256
- Canada (ZC01)
- Effective Date:
- 1 Sep 2002
Approved Sources 5120-01-434-9256
- Part Number
- Manufacturer
- Status
- 78-000
- Manufacturer
- 636D0 - Apex Tool Group, Llc (Active)
- Primary Buy
- Primary Buy
- 78-000
- 08292 - Easco Hand Tools Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 78-000
- 03914 - Armstrong Bros Tool Co (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-01-434-9256
- Characteristic
- Specifications
- FIIG
- Specifications
- T294-L
- Test Load Rating [BSKJ]
- 2800.0 Pounds
- Throat Depth [AQCL]
- 0.625 Inches Nominal
- Jaw Nominal Opening [BSKN]
- 0.812 Inches
- Special Features [FEAT]
- Square Head Screw; 3/8 In. Screw Dia
Management Data 5120-01-434-9256
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Jan 2008
- Department of the Air Force (DF)
- EA
- Subscribe
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Air Force (DF)
- F
- N
- Disposal
- N
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Similar Supply Items to 5120-01-434-9256
Freight Information 5120-01-434-9256
5120-01-434-9256 has freight characteristics.. 5120-01-434-9256 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
