5120-01-434-9217
Drive Pin Punch
5120014349217 014349217 70-105 456720005907
INC 03851 REINSTATED ON 030405~A round, square, hexagonal or octagonal bodied hand tool, having a flat blunt face. Includes tapered items whose taper length is less than 4 inches (101.6 mm). The tapered items are normally used to start out, pins, bolts, and the like from holes having a force or drive fit, and the straight items to follow thru or finish driving out. For tapered items having a taper length of 4 inches (101.6 mm) or more, see PUNCH, DRIFT and PUNCH, ALIGNING. See also NAIL SET. View more Drive Pin Punch
May 2023
19
Marketplace 5120-01-434-9217
Request a Quotation from participating marketplace vendors
Related Documents 5120-01-434-9217 5+ Documents (More...)
,DRIVE PIN RQST NS Request Quotation Updated Every Day 70-105 RQST NE Updated Every Day 5120-01-434-9217
5120-01-434-9217 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-434-9217
Restrictions 5120-01-434-9217
5120-01-434-9217 is a Drive Pin Punch that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-434-9217
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-434-9217
- US Army (A192)
- Effective Date:
- 1 Sep 2014
- Supplementary Receivers:
- AZ
- NASA (G751)
- Effective Date:
- 1 Jun 2013
- US Marine Corps (MC14)
- Effective Date:
- 1 Jun 2013
- US Navy (N9QG)
- Effective Date:
- 1 Jan 2014
- Supplementary Collaborators:
- GGGT
- Hungary (WH01)
- Effective Date:
- 1 Jul 2011
- Belgium (ZB01)
- Effective Date:
- 1 Sep 2000
- Denmark (ZS01)
- Effective Date:
- 1 Jul 2005
Approved Sources 5120-01-434-9217
- Part Number
- Manufacturer
- Status
- 70-105
- Manufacturer
- 636D0 - Apex Tool Group, Llc (Active)
- Primary Buy
- Primary Buy
- 70-105
- 03914 - Armstrong Bros Tool Co (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 70-105
- 08292 - Easco Hand Tools Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 456720005907
- 0000V - Ncb Hungary (Honvedsegi Egyseges (Active)
- NATO Reference
- NATO Reference
Datasheet 5120-01-434-9217
- Characteristic
- Specifications
- FIIG
- Specifications
- A531R0
- Material [MATT]
- Steel
- Overall Length [ABHP]
- 4.750 Inches Nominal
- Shank Shape [ASWL]
- Hexagon
- Shank Width Across Flats [BWLP]
- 0.312 Inches Nominal
- Point Size [CLBT]
- 0.125 Inches
Similar Supply Items to 5120-01-434-9217
Freight Information 5120-01-434-9217
5120-01-434-9217 has freight characteristics.. 5120-01-434-9217 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
