5120-01-434-9192
C Clamp
5120014349192 014349192 78-015
A clamping device in the shape of the letter C having a screw with or without a swivel button at the contact end, and a thumbscrew, T-handle, or square-end drive. Excludes CLAMP, LOOP. View more C Clamp
May 2023
11
Marketplace 5120-01-434-9192
Request a Quotation from participating marketplace vendors
Related Documents 5120-01-434-9192 2+ Documents (More...)
/fsg-51/fsc-5120/us
C Clamp 5120014349192 014349192,78-015 CLAMP,C 10 EA NS Request Quotation Updated Every Day 78-015 RQST
NE Updated Every Day 5120-01-434-9192 C Clamp 5120014349192 014349192,78-015 CLAMP,C 10 EA NS Request
Restrictions 5120-01-434-9192
5120-01-434-9192 is a C Clamp that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-434-9192
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-434-9192
- Canada (ZC01)
- Effective Date:
- 1 Sep 2002
Approved Sources 5120-01-434-9192
- Part Number
- Manufacturer
- Status
- 78-015
- Manufacturer
- 636D0 - Apex Tool Group, Llc (Active)
- Primary Buy
- Primary Buy
- 78-015
- 03914 - Armstrong Bros Tool Co (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 78-015
- 08292 - Easco Hand Tools Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-01-434-9192
- Characteristic
- Specifications
- FIIG
- Specifications
- T294-L
- Test Load Rating [BSKJ]
- 8750.0 Pounds
- Throat Depth [AQCL]
- 1.375 Inches Nominal
- Jaw Nominal Opening [BSKN]
- 1.750 Inches
- Special Features [FEAT]
- Square Head Screw; 5/8 In. Screw Dia
Similar Supply Items to 5120-01-434-9192
Freight Information 5120-01-434-9192
5120-01-434-9192 has freight characteristics.. 5120-01-434-9192 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
