5120-01-428-5188
Hand Hammer
5120014285188 014285188 57-552 57.552 00072407 6R343 12 HD
A tool with a striking face on one or both ends of a metallic weighted head fixed crosswise to a handle. It is used to strike and/or drive objects, or beat malleable materials. For items stocked without FACE, HAMMER, INSERTED, see HOLDER, INSERTED HAMMER FACE. Excludes DRIVER, COOPER'S and mechanical hammers. See also MALLET (as modified). View more Hand Hammer
May 2023
20
Marketplace 5120-01-428-5188
Request a Quotation from participating marketplace vendors
Related Documents 5120-01-428-5188 5+ Documents (More...)
RQST NS Request Quotation Updated Every Day 57-552 RQST NE Updated Every Day 57.552 RQST NE Updated
Every Day 6R343 RQST NE Updated Every Day 5120-01-428-5188 RQST NE Updated Every Day 5120-01-428-5188
https//www.nsnlookup.com /fsg-51/fsc-5120/au 5120-66-150-0130 Hand Hammer 5120661500130661500130 00072407
Day 5120-66-150-0130 RQST NE Related Documents https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-428-5188
Documents ( More... ) https//www.nsnlookup.com https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-428-5188
Hand Hammer 5120014285188 014285188,57-552 Upgrade your Account Upgrade 5120-01-428-5188Hand Hammer5120014285188
Hand Hammer 5120014285188 014285188,57-552 Upgrade 5120-01-428-5188Hand Hammer5120014285188 https
AssyUOMTechnical DocumentQuantative ExpressionDepartment of the Navy (DN)NZDiscontinued-Use 5120-01-428-5188
Restrictions 5120-01-428-5188
5120-01-428-5188 is a Hand Hammer that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-428-5188
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-428-5188
- US Army (A192)
- Effective Date:
- 1 May 1996
- US Air Force (FGGS)
- Effective Date:
- 1 May 1996
- NASA (G751)
- Effective Date:
- 1 Mar 1996
- US Marine Corps (MC14)
- Effective Date:
- 1 May 1996
- US Navy (N9QG)
- Effective Date:
- 1 May 1996
- Supplementary Collaborators:
- GTJNHD
- Australia (ZA01)
- Effective Date:
- 1 Jun 2010
- Canada (ZC01)
- Effective Date:
- 1 Dec 1998
- New Zealand (ZE01)
- Effective Date:
- 1 May 2002
Approved Sources 5120-01-428-5188
- Part Number
- Manufacturer
- Status
- 57-552
- Manufacturer
- 1CV05 - The Stanley Works (Active)
- Primary Buy
- Primary Buy
- 57.552
- Z0557 - The Stanley Works Pty Ltd (Active)
- Secondary Buy
- Secondary Buy
- 00072407
- ZD484 - J. Blackwood & Son Pty Ltd (Active)
- Secondary Buy
- Secondary Buy
- 6R343
- 25795 - W.W. Grainger, Inc. (Active)
- Secondary Buy
- Secondary Buy
- 57-552
- 78525 - Stanley Tools Div Of Stanley Works (Active)
- Secondary Buy
- Secondary Buy
- 12 HD
- 55424 - Compo-Cast Div Of C E S Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-01-428-5188
- Characteristic
- Specifications
- FIIG
- Specifications
- A526S0
- Style Designator [STYL]
- Sledge, Blacksmith's Double-Faced
- Head Weight [AHRU]
- 10.500 Pounds
- Handle Material [CYAS]
- Steel
- Head Length [AASV]
- 8.000 Inches Nominal
- Overall Length [ABHP]
- 30.000 Inches Nominal
- Face Diameter [ARGG]
- 3.500 Inches Nominal
- Special Features [FEAT]
- Dead Blow; Urethane Coated Head, Handle And Faces
Management Data 5120-01-428-5188
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- D
- Durable item.An item of Army property coded with an ARC of D in the AMDF. Durable items do not require property book accountability after issue from the stock record account but do require hand receipt control when issued to the user. Commercial and fabricated items similar to items coded D in the AMDF are considered durable items.
Navy
- Cognizance:
- 9Q
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- 02
- Operational Test:
- No Special Procedures
Similar Supply Items to 5120-01-428-5188
Freight Information 5120-01-428-5188
5120-01-428-5188 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186620. A Sub NMFC of Z. It has a NMFC Description of TOOLS, NOI HAND OTHER THAN POWER. 5120-01-428-5188 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5120-01-428-5188 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5120-01-428-5188 is not classified as a special type of cargo when transported by water. 5120-01-428-5188 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
