5120-01-428-4741
Socket Wrench Socket
5120014284741 014284741 B107.1 B107.1 TY1CL2 J5328H 1AN99 5328H
An item having an internal drive at one end made to fit into the external drive end of a socket wrench handle, torque wrench, or power driven tool. The opposite end consists of various internal wrench shapes such as hexagon or square. It may include an integral universal joint. View more Socket Wrench Socket
May 2023
9
Marketplace 5120-01-428-4741
Request a Quotation from participating marketplace vendors
Related Documents 5120-01-428-4741 5+ Documents (More...)
5328H RQST NE Updated Every Day 1AN99 RQST NE Updated Every Day 5120-01-428-4741 RQST NE Updated Every
drive B107.1 TY1CL2 IN2816TD GGG-W an internal drive B107.1 TY1CL2 drive B107.1 TY1CL2 having an internal
vendors Request FedMall Updated Every 15 Minutes 5120-01-648-5660 BUY NE FedMall Updated Every Day J5328H
Socket Wrench Socket 5120014284741 014284741 Account Upgrade 5120-01-428-4741Socket Wrench Socket5120014284741
/fsg-51/fsc-5120/us
drive B107.1 TY1CL2 having an internal drive B107.1 TY1CL2 IN2816TD GGG-W an internal drive B107.1 TY1CL2
drive B107.1 TY1CL2 drive B107.1 TY1CL2 having an internal drive B107.1 TY1CL2 IN2816TD GGG-W an internal
drive B107.1 TY1CL2 having an internal drive B107.1 TY1CL2 IN2816TD GGG-W an internal drive B107.1 TY1CL2
drive B107.1 TY1CL2 having an internal drive B107.1 TY1CL2 IN2816TD GGG-W an internal drive B107.1 TY1CL2
TY1CL2 IN2816TD having an internal drive B107.1 TY1CL2 TY1CL2 having an internal drive B107.1 TY1CL2
IN2816TD drive B107.1 TY1CL2 having an internal drive B107.1 TY1CL2 IN2816TD GGG-W an internal drive
Restrictions 5120-01-428-4741
5120-01-428-4741 is a Socket Wrench Socket that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-428-4741
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-428-4741
- US Army (A192)
- Effective Date:
- 1 May 1996
- US Coast Guard (C014)
- Effective Date:
- 1 May 1996
- US Air Force (FGGS)
- Effective Date:
- 1 May 1996
- NASA (G751)
- Effective Date:
- 1 Mar 1996
- US Marine Corps (MC14)
- Effective Date:
- 1 May 1996
- US Navy (N9QG)
- Effective Date:
- 1 Jun 2004
Approved Sources 5120-01-428-4741
- Part Number
- Manufacturer
- Status
- B107.1
- Manufacturer
- 05047 - The American Society Of Mechanical (Active)
- Incomplete Reference
- Incomplete Reference
- B107.1 TY1CL2
- 80244 - General Services Administration (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- J5328H
- 1CV05 - The Stanley Works (Active)
- Secondary Buy
- Secondary Buy
- 1AN99
- 25795 - W.W. Grainger, Inc. (Active)
- Secondary Buy
- Secondary Buy
- 5328H
- 1CV05 - The Stanley Works (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-01-428-4741
- Characteristic
- Specifications
- FIIG
- Specifications
- A102A0
- Drive End Shape [CTCT]
- Square Single End Internal
- Drive Surface Size [ATNC]
- 0.500 Inches Nominal Single End
- Features Provided [CBBL]
- Manual Tool
- Material [MATT]
- Steel Overall
- Nondefinitive Spec/Std Data [ZZZT]
- 1 Type And 2 Class
- Overall Length [ABHP]
- 3.250 Inches Nominal
- Special Features [FEAT]
- Deep Length
- Wrenching Surface Shape [CRWY]
- 6 Point Single End Internal
- Wrenching Surface Size [AJBR]
- 0.875 Inches Nominal Single End
- Specification/Standard Data [ZZZK]
- 05047-Asme B107.1 Professional/Industrial Association Standard
- Style Designator [STYL]
- Internal-Internal
- Surface Treatment [SFTT]
- Chromium Overall
Management Data 5120-01-428-4741
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Feb 2020
- Department of the Air Force (DF)
- EA
- Subscribe
- EA
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9Q
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 2
- Non-Critical Repair Part
- Echelon Management:
- 02
- Operational Test:
- No Special Procedures
NATO Stock Numbers Related to 5120-01-428-4741
Freight Information 5120-01-428-4741
5120-01-428-4741 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186620. A Sub NMFC of Z. It has a NMFC Description of TOOLS, NOI HAND OTHER THAN POWER. 5120-01-428-4741 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5120-01-428-4741 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5120-01-428-4741 is not classified as a special type of cargo when transported by water. 5120-01-428-4741 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
