5120-01-425-8873
Socket Wrench Socket
5120014258873 014258873 2008 5543A23
An item having an internal drive at one end made to fit into the external drive end of a socket wrench handle, torque wrench, or power driven tool. The opposite end consists of various internal wrench shapes such as hexagon or square. It may include an integral universal joint. View more Socket Wrench Socket
May 2023
10
Marketplace 5120-01-425-8873
Request a Quotation from participating marketplace vendors
Updated Every Day
Updated Every Day Updated Every Day
Updated Every Day Related Documents 5120-01-425-8873 5+ Documents (More...)
Request a Quotation from participating marketplace vendors Request Global Test Supply 2008 Dwyer 2008
1130 EA NS Request Quotation Updated Every Day 5543A23 RQST NE Updated Every Day 5120-01-425-8873 RQST
Restrictions 5120-01-425-8873
5120-01-425-8873 is a Socket Wrench Socket that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-425-8873
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-425-8873
- Italy (ZR01)
- Effective Date:
- 1 Jul 2014
Approved Sources 5120-01-425-8873
- Part Number
- Manufacturer
- Status
- 2008
- Manufacturer
- 79808 - Wright Tool Co (Active)
- Primary Buy
- Primary Buy
- 5543A23
- 39428 - Mcmaster-Carr Supply Co (Active)
- Secondary Buy
- Secondary Buy
Datasheet 5120-01-425-8873
- Characteristic
- Specifications
- FIIG
- Specifications
- A102A0
- Drive End Shape [CTCT]
- Square Single End Internal
- Drive Surface Size [ATNC]
- 0.250 Inches Nominal Single End
- Features Provided [CBBL]
- Manual Tool
- Material [MATT]
- Steel Overall
- Supplementary Features [SUPP]
- Industrial Quality (Iq) Tools Program Item
- Overall Length [ABHP]
- 1.000 Inches Nominal
- Special Features [FEAT]
- Standard Length
- Wrenching Surface Shape [CRWY]
- 6 Point Single End Internal
- Wrenching Surface Size [AJBR]
- 0.250 Inches Nominal Single End
- Style Designator [STYL]
- Internal-Internal
- Surface Treatment [SFTT]
- Chromium Overall
Similar Supply Items to 5120-01-425-8873
Freight Information 5120-01-425-8873
5120-01-425-8873 has freight characteristics.. 5120-01-425-8873 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
