5120-01-400-0319
Torque Wrench
5120014000319 014000319 AS28431 TY1CL2 J6020AB 1ARN1 6020-1 B107.300 6020A 6020AB B107.14 TY2CLAST2DEA AS28431 6020 B107.14
A manual tool for tightening various fasteners to a precise torque value. Consists of a handle and drive to accommodate female square drive sockets and other types of wrenching adapters. Torque value may be manually set and adjusted by user or may be provided as preset for production line use. A signaling device is generally provided to indicate when set torque value is reached. Handle is swung at right angle to axis of fastener rotation to apply torque. For items with handles that are spun in-line with axis of fastener rotation to apply torque, see SCREWDRIVER, TORQUE. View more Torque Wrench
November 2023
37





Marketplace 5120-01-400-0319
Request a Quotation from participating marketplace vendors














Related Documents 5120-01-400-0319 5+ Documents (More...)
TY1CL2 AS28431 QJR3200A B107.14 TY2CLAST2DEA QJR3200 QJR3200B B107.14 TY2CLAST2DEAB107.14 TY1CL2B107.300B107.14
2477 GGG-W-686 TY3CL2 B107.14 TY2CLAST2DEA 28414 TY2CLAST2DEA 28414 AS28431 TY1CL2 https//www.nsnlookup.com
AS28431 QJR3200A B107.14 TY2CLAST2DEA https//www.nsnlookup.com https//www.nsnlookup.com /fsg-51/fsc-
28414 TY2CLAST2DEA 28414 AS28431 TY1CL2 fasteners B107.14 TY2CLAST2DEA 28414 TY2CLAST2DEA -01-400-0239
TY2CLAST2DEA AS28431 TY1CL2 TCI-150 TCI-150RA TW150R 2477 GGG-W-686 TY3CL2 B107.14 TY2CLAST2DEA https
AS28431 QJR3200A B107.14 TY2CLAST2DEA https//www.nsnlookup.com /fsg https//www.nsnlookup.com https//
Torque Wrench 5120014000319 014000319 Upgrade for $1 a day Upgrade your Account Upgrade 5120-01
-400-0319Torque Wrench5120014000319 014000319 AS28431 TY1CL2 TCI https Wrench 5120013551776 013551776
Torque Wrench 5120014000319 014000319 Photo 1/5 5120-01-400-0319 Photo 2/5 5120-01-400-0319 Photo
3/5 5120-01-400-0319 Photo 4/5 NSN 5120- 5120-01-400-0319 5+ Documents ( More... ) https//www.nsnlookup.com
Restrictions 5120-01-400-0319
5120-01-400-0319 is a Torque Wrench that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-400-0319
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-400-0319
- US Army (A192)
- Effective Date:
- 1 Jan 1995
- Supplementary Receivers:
- AZBF
- US Coast Guard (C014)
- Effective Date:
- 1 Jan 1995
- US Air Force (FGGS)
- Effective Date:
- 1 Jan 1995
- NASA (G751)
- Effective Date:
- 1 Dec 1994
- US Marine Corps (MC14)
- Effective Date:
- 1 Jan 1995
- US Navy (N9QG)
- Effective Date:
- 1 Jan 1995
- Supplementary Collaborators:
- GTHD
- Singapore (YJ01)
- Effective Date:
- 1 Sep 1998
- Canada (ZC01)
- Effective Date:
- 1 Nov 2010
- Republic of Korea (ZH01)
- Effective Date:
- 1 Jun 2000
Approved Sources 5120-01-400-0319
- Part Number
- Manufacturer
- Status
- AS28431
- Manufacturer
- 0U583 - Sae International (Active)
- Incomplete Reference
- Incomplete Reference
- AS28431 TY1CL2
- 80244 - General Services Administration (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- J6020AB
- 1CV05 - The Stanley Works (Active)
- Secondary Buy
- Secondary Buy
- 1ARN1
- 25795 - W.W. Grainger, Inc. (Active)
- Secondary Buy
- Secondary Buy
- J6020AB
- Z19N0 - The Trustee For Henchman Unit Trust (Active)
- Secondary Buy
- Secondary Buy
- 6020-1
- 09669 - Stanley Canada Incstanley Proto Div (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- B107.300
- 05047 - The American Society Of Mechanical (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 6020A
- 1CV05 - The Stanley Works (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 6020AB
- 1CV05 - The Stanley Works (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- B107.14 TY2CLAST2DEA
- 80244 - General Services Administration (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- AS28431
- 81343 - Society Of Automotive Engineers Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 6020
- 09669 - Stanley Canada Incstanley Proto Div (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- B107.14
- 05047 - The American Society Of Mechanical (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- J6020AB
- ZAE87 - Henchman Products Pty Ltd (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-01-400-0319
- Characteristic
- Specifications
- FIIG
- Specifications
- A102A0
- Drive End Shape [CTCT]
- Square Single End External
- Drive Surface Size [ATNC]
- 0.750 Inches Nominal Single End
- Furnished Items [AFJH]
- Case
- Material [MATT]
- Steel Overall
- Nondefinitive Spec/Std Data [ZZZT]
- 1 Type And 2 Class
- Overall Length [ABHP]
- 41.500 Inches Nominal
- Special Features [FEAT]
- Ratchet Head; Plain Steel Handle; Dual Scale; 0.28 Mkg Graduations
- Torque Scale Graduation [AJCH]
- 2.00 Foot-Pounds
- Torque Signal Method [AJDR]
- Audible
- Torque Capacity [AJCG]
- 120.0 Foot-Pounds Minimum And 600.0 Foot-Pounds Maximum And 162.69 Meter-Newton Minimum And 813.45 Meter-Newton Maximum
- Torque Indicating Mechanism [AJCF]
- Micrometer
- Specification/Standard Data [ZZZK]
- 81343-Sae As28431 Professional/Industrial Association Standard
- Style Designator [STYL]
- Micrometer End Drive
- Surface Treatment [SFTT]
- Chromium Overall
Management Data 5120-01-400-0319
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Jan 2023
- Department of the Air Force (DF)
- EA
- Subscribe
- EA
- Jul 2019
- Department of the Air Force (DF)
- EA
- Subscribe
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- US Marine Corps (DM)
- M
- 0
- Reversal Of Phrase Code Z 5120-01-589-8714
- 0
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- D
- Durable item.An item of Army property coded with an ARC of D in the AMDF. Durable items do not require property book accountability after issue from the stock record account but do require hand receipt control when issued to the user. Commercial and fabricated items similar to items coded D in the AMDF are considered durable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of āLā or āFā, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9Q
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- 02
- Operational Test:
- 3
- Calibration Required
NATO Stock Numbers Related to 5120-01-400-0319
Freight Information 5120-01-400-0319
5120-01-400-0319 has freight characteristics.. 5120-01-400-0319 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
