5120-01-400-0241
Torque Wrench
5120014000241 014000241 AS28431 TY1CL2 STP 6016C J6016C 4LY35 6016B B107.14 6016 6016C AS28431 1ARM8 B107.300 B107.14 TY2CLAST2DEA
A manual tool for tightening various fasteners to a precise torque value. Consists of a handle and drive to accommodate female square drive sockets and other types of wrenching adapters. Torque value may be manually set and adjusted by user or may be provided as preset for production line use. A signaling device is generally provided to indicate when set torque value is reached. Handle is swung at right angle to axis of fastener rotation to apply torque. For items with handles that are spun in-line with axis of fastener rotation to apply torque, see SCREWDRIVER, TORQUE. View more Torque Wrench
Managed by United States
NSN Created on 7 Dec 1994
Data Last Changed
November 2023
November 2023
NATO Update Count
31
31
NATO Data Quality
Marketplace 5120-01-400-0241
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Updated Every Day J6016C RQST NE
Updated Every Day 6016B RQST NE
Updated Every Day 6016 RQST NE
Updated Every Day 6016C RQST NE
Updated Every Day 4LY35 RQST NE
Updated Every Day 1ARM8 RQST NE
Updated Every Day 5120-01-400-0241 RQST NE
Updated Every Day 5120-01-400-0241 RQST
Updated Every Day 5120-01-400-0241 RQST NE
Related Documents 5120-01-400-0241 5+ Documents (More...)
AS28431 TY1CL2 STP 6016C J6016C 4LY35 6016B B107.14 6016 6016C AS28431 1ARM8 B107.300 B107.14 TY2CLAST2DEA
J6016C RQST NE Updated Every Day 6016B RQST NE Updated Every Day 6016 RQST NE Updated Every Day 6016C
Day 6016C RQST NE Updated Every Day 4LY35 RQST NE Updated Every Day 1ARM8 RQST NE Updated Every Day
J6016C RQST NE Updated Every Day 6016B RQST NE Updated Every Day 6016 RQST NE Updated Every Day 6016C
Day 6016C RQST NE Updated Every Day 4LY35 RQST NE Updated Every Day 1ARM8 RQST NE Updated Every Day
Upgrade for $1 a day Upgrade your Account Upgrade 5120-01-593-0601Torque Wrench5120015930601 015930601 STP 6016C
M4Reversal -5999/us 5999-01-249-7173 Electrical-Electronic Component Heat Sink RNCC 5 RNVC 1 DAC 4 STP 6016C
Electrical-Electronic Component Heat Sink RNCC 5 RNVC 1 DAC 4 STP 6016C J6016C your Account Upgrade
M4Reversal -5999/us 5999-01-249-7173 Electrical-Electronic Component Heat Sink RNCC 5 RNVC 1 DAC 4 STP 6016C
Electrical-Electronic Component Heat Sink RNCC 5 RNVC 1 DAC 4 STP 6016C J6016C your Account Upgrade
M4Reversal -5999/us 5999-01-249-7173 Electrical-Electronic Component Heat Sink RNCC 5 RNVC 1 DAC 4 STP 6016C
Heat Sink your Account Upgrade Electrical-Electronic Component Heat Sink RNCC 5 RNVC 1 DAC 4 STP 6016C
/fsg-59 https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-400-0241 Torque Wrench 5120014000241 014000241
Heat Sink your Account Upgrade Electrical-Electronic Component Heat Sink RNCC 5 RNVC 1 DAC 4 STP 6016C
/fsg-59 https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-400-0241 Torque Wrench 5120014000241 014000241
Electrical-Electronic Component Heat Sink RNCC 5 RNVC 1 DAC 4 STP 6016C J6016C https//www.nsnlookup.com
Electrical-Electronic Component Heat Sink RNCC 5 RNVC 1 DAC 4 STP 6016C J6016C 014000241AS28431 https
//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-400-0241 Torque Wrench 5120014000241 014000241 Upgrade
Electrical-Electronic Component Heat Sink RNCC 5 RNVC 1 DAC 4 STP 6016C J6016C 014000241AS28431 https
//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-400-0241 Torque Wrench 5120014000241 014000241 Upgrade
Component Heat Sink your Account Upgrade Electrical-Electronic Component Heat Sink RNCC 5 RNVC 1 DAC 4 STP 6016C
-5999/us 5999-01-249-7173 Electrical-Electronic Component Heat Sink RNCC 5 RNVC 1 DAC 4 STP 6016C J6016C
us 5120-01-504-2576 https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-400-0241 Torque Wrench 5120014000241
-5999/us 5999-01-249-7173 Electrical-Electronic Component Heat Sink RNCC 5 RNVC 1 DAC 4 STP 6016C J6016C
us 5120-01-504-2576 https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-400-0241 Torque Wrench 5120014000241
Restrictions 5120-01-400-0241
5120-01-400-0241 is a Torque Wrench that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-400-0241
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-400-0241
- US Army (A192)
- Effective Date:
- 1 Jan 1995
- US Coast Guard (C014)
- Effective Date:
- 1 Jan 1995
- US Air Force (FGGS)
- Effective Date:
- 1 Jan 1995
- NASA (G751)
- Effective Date:
- 1 Dec 1994
- US Marine Corps (MC14)
- Effective Date:
- 1 Jan 1995
- US Navy (N9QG)
- Effective Date:
- 1 Jan 2014
- Supplementary Collaborators:
- GGGT
- Canada (ZC01)
- Effective Date:
- 1 Dec 2013
- Republic of Korea (ZH01)
- Effective Date:
- 1 Dec 2013
Approved Sources 5120-01-400-0241
- Part Number
- Manufacturer
- Status
- AS28431
- Manufacturer
- 0U583 - Sae International (Active)
- Incomplete Reference
- Incomplete Reference
- AS28431 TY1CL2
- 80244 - General Services Administration (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- STP 6016C
- 00NS2 - Kipper Tool Company (Active)
- Secondary Buy
- Secondary Buy
- J6016C
- 1CV05 - The Stanley Works (Active)
- Secondary Buy
- Secondary Buy
- 4LY35
- 25795 - W.W. Grainger, Inc. (Active)
- Secondary Buy
- Secondary Buy
- 6016B
- 1CV05 - The Stanley Works (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- B107.14
- 05047 - The American Society Of Mechanical (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 6016
- 1CV05 - The Stanley Works (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 6016C
- 1CV05 - The Stanley Works (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- AS28431
- 81343 - Society Of Automotive Engineers Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 1ARM8
- 25795 - W.W. Grainger, Inc. (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- B107.300
- 05047 - The American Society Of Mechanical (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- B107.14 TY2CLAST2DEA
- 80244 - General Services Administration (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-01-400-0241
- Characteristic
- Specifications
- FIIG
- Specifications
- A102A0
- Drive End Shape [CTCT]
- Square Single End External
- Drive Surface Size [ATNC]
- 0.500 Inches Nominal Single End
- Furnished Items [AFJH]
- Case
- Material [MATT]
- Steel Overall
- Nondefinitive Spec/Std Data [ZZZT]
- 1 Type And 2 Class
- Overall Length [ABHP]
- 20.750 Inches Nominal
- Special Features [FEAT]
- Ratchet Head; Plain Steel Handle; Dual Scale; 0.14 Mkg Graduations
- Torque Scale Graduation [AJCH]
- 1.00 Foot-Pounds
- Torque Signal Method [AJDR]
- Audible
- Torque Capacity [AJCG]
- 30.0 Foot-Pounds Minimum And 150.0 Foot-Pounds Maximum And 4.8 Meter-Kilograms Minimum And 21.4 Meter-Kilograms Maximum
- Torque Indicating Mechanism [AJCF]
- Micrometer
- Specification/Standard Data [ZZZK]
- 81343-Sae As28431 Professional/Industrial Association Standard
- Style Designator [STYL]
- Micrometer End Drive
- Surface Treatment [SFTT]
- Chromium Overall
Management Data 5120-01-400-0241
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2021
- Department of the Air Force (DF)
- EA
- Subscribe
- EA
- Apr 2021
- Department of the Air Force (DF)
- EA
- Subscribe
- EA
- Feb 2020
- Department of the Air Force (DF)
- EA
- Subscribe
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- US Marine Corps (DM)
- M
- 4
- Reversal Of Phrase Code A 5120-01-593-0601
- 4
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- D
- Durable item.An item of Army property coded with an ARC of D in the AMDF. Durable items do not require property book accountability after issue from the stock record account but do require hand receipt control when issued to the user. Commercial and fabricated items similar to items coded D in the AMDF are considered durable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9Q
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- 02
- Operational Test:
- 3
- Calibration Required
NATO Stock Numbers Related to 5120-01-400-0241
5120-66-154-5290 5120-12-384-3257 5120-25-135-7395 5120-21-870-1566 5120-12-312-4120 5120-99-433-0354 5120-99-788-6215 5120-99-122-6175 5120-22-125-4799 5120-34-030-0586 5120-12-345-4269 5120-12-367-1978 5120-99-258-1646 5120-99-108-9853 5120-99-738-9953 5120-22-309-1479 5120-21-880-8042 5120-99-739-0718
Freight Information 5120-01-400-0241
5120-01-400-0241 has freight characteristics.. 5120-01-400-0241 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
