5120-01-400-0232
Torque Wrench
5120014000232 014000232 AS28431 TY1CL2 J6062C 4LY15 B107.300 B107.14 6062A AS28431 6062AB B107.14M 6062C B107.14 TY2CLAST2DEA B107.14M TY2CLAST2DEA 1ARL5
A manual tool for tightening various fasteners to a precise torque value. Consists of a handle and drive to accommodate female square drive sockets and other types of wrenching adapters. Torque value may be manually set and adjusted by user or may be provided as preset for production line use. A signaling device is generally provided to indicate when set torque value is reached. Handle is swung at right angle to axis of fastener rotation to apply torque. For items with handles that are spun in-line with axis of fastener rotation to apply torque, see SCREWDRIVER, TORQUE. View more Torque Wrench
November 2023
37
Marketplace 5120-01-400-0232
Request a Quotation from participating marketplace vendors
Updated Every Day Updated Every Day Updated Every Day Updated Every Day
Updated Every Day Updated Every Day
Updated Every Day Updated Every Day
Updated Every Day Related Documents 5120-01-400-0232 5+ Documents (More...)
Every Day 1ARL5 B107.14 011255190 TY1CL2 AS28431 QJR3200A B107.14 TY2CLAST2DEA QJR3200 QJR3200B B107.14
QJR3200A B107.14 TY2CLAST2DEA QJR3200 QJR3200B B107.14 TY1CL2 AS28431 QJR3200A B107.14 TY2CLAST2DEA
AS28431 QJR3200A B107.14 TY2CLAST2DEA QJR3200 QJR3200B B107.14 TY2CLAST2DEA https//www.nsnlookup.com
QJR3200B B107.14 TY1CL2 AS28431 QJR3200A B107.14 TY2CLAST2DEA AS28431 QJR3200A B107.14 https//www.nsnlookup.com
AS28431 QJR3200A B107.14 TY2CLAST2DEA QJR3200 QJR3200B B107.14 TY2CLAST2DEA https//www.nsnlookup.com
TY1CL2 AS28431 QJR3200A B107.14 TY2CLAST2DEA QJR3200 QJR3200B B107.14 TY2CLAST2DEA TY3CL2 B107.14 011255190
TY1CL2 AS28431 QJR3200A B107.14 TY2CLAST2DEA QJR3200 QJR3200B B107.14 TY2CLAST2DEA TY3CL2 B107.14 011255190
QJR3200A B107.14 TY2CLAST2DEA QJR3200 QJR3200B B107.14 TY1CL2 AS28431 QJR3200A B107.14 TY2CLAST2DEA
AS28431 QJR3200A B107.14 TY2CLAST2DEA QJR3200 QJR3200B B107.14 TY2CLAST2DEA https//www.nsnlookup.com
B107.14M TY2CLAST2DEA TY1CL2 AS28431 QJR3200A B107.14 TY2CLAST2DEA QJR3200 QJR3200B B107.14 https//www.nsnlookup.com
Restrictions 5120-01-400-0232
5120-01-400-0232 is a Torque Wrench that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-400-0232
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-400-0232
- US Army (A192)
- Effective Date:
- 1 Jan 1995
- Supplementary Receivers:
- CT
- US Air Force (FGGS)
- Effective Date:
- 1 Jan 1995
- NASA (G751)
- Effective Date:
- 1 Dec 1994
- US Navy (N9QG)
- Effective Date:
- 1 Jan 2014
- Supplementary Collaborators:
- GG
- Singapore (YJ01)
- Effective Date:
- 1 Jun 2005
- Australia (ZA01)
- Effective Date:
- 1 Aug 2005
- Canada (ZC01)
- Effective Date:
- 1 Dec 2006
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 2002
- Turkey (ZW01)
- Effective Date:
- 1 Dec 2005
Approved Sources 5120-01-400-0232
- Part Number
- Manufacturer
- Status
- AS28431
- Manufacturer
- 0U583 - Sae International (Active)
- Incomplete Reference
- Incomplete Reference
- AS28431 TY1CL2
- 80244 - General Services Administration (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 6062A
- Z0557 - The Stanley Works Pty Ltd (Active)
- Secondary Buy
- Secondary Buy
- J6062C
- 1CV05 - The Stanley Works (Active)
- Secondary Buy
- Secondary Buy
- 4LY15
- 25795 - W.W. Grainger, Inc. (Active)
- Secondary Buy
- Secondary Buy
- B107.300
- 05047 - The American Society Of Mechanical (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- B107.14
- 05047 - The American Society Of Mechanical (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 6062A
- 1CV05 - The Stanley Works (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- AS28431
- 81343 - Society Of Automotive Engineers Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 6062AB
- 1CV05 - The Stanley Works (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- B107.14M
- 05047 - The American Society Of Mechanical (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 6062C
- 1CV05 - The Stanley Works (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- B107.14 TY2CLAST2DEA
- 80244 - General Services Administration (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- B107.14M TY2CLAST2DEA
- 80244 - General Services Administration (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 1ARL5
- 25795 - W.W. Grainger, Inc. (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-01-400-0232
- Characteristic
- Specifications
- FIIG
- Specifications
- A102A0
- Drive End Shape [CTCT]
- Square Single End External
- Drive Surface Size [ATNC]
- 0.250 Inches Nominal Single End
- Furnished Items [AFJH]
- Case
- Material [MATT]
- Steel Overall
- Nondefinitive Spec/Std Data [ZZZT]
- 1 Type And 2 Class
- Overall Length [ABHP]
- 11.250 Inches Nominal
- Special Features [FEAT]
- Ratchet Head; Plain Steel Handle; Dual Scale; 1.15 Cmkg Graduations
- Torque Scale Graduation [AJCH]
- 1.00 Inch-Pounds
- Torque Signal Method [AJDR]
- Audible
- Torque Capacity [AJCG]
- 40.0 Inch-Pounds Minimum And 200.0 Inch-Pounds Maximum And 58.0 Centimeter-Kilograms Minimum And 242.0 Centimeter-Kilograms Maximum
- Torque Indicating Mechanism [AJCF]
- Micrometer
- Specification/Standard Data [ZZZK]
- 81343-Sae As28431 Professional/Industrial Association Standard
- Style Designator [STYL]
- Micrometer End Drive
- Surface Treatment [SFTT]
- Chromium Overall
Management Data 5120-01-400-0232
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- D
- Durable item.An item of Army property coded with an ARC of D in the AMDF. Durable items do not require property book accountability after issue from the stock record account but do require hand receipt control when issued to the user. Commercial and fabricated items similar to items coded D in the AMDF are considered durable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9Q
NATO Stock Numbers Related to 5120-01-400-0232
Freight Information 5120-01-400-0232
5120-01-400-0232 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186620. A Sub NMFC of Z. It has a NMFC Description of TOOLS, NOI HAND OTHER THAN POWER. 5120-01-400-0232 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5120-01-400-0232 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5120-01-400-0232 is not classified as a special type of cargo when transported by water. 5120-01-400-0232 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
