5120-01-399-9821
Socket Wrench Screwdriver Attachment
5120013999821 013999821 J4990-5MXL 1AL87 4990-5MXL
An attachment designed to fit over the square external drive end of a HANDLE, SOCKET WRENCH; WRENCH, TORQUE; and the like consisting of one or two-piece configuration having a screw driving tip on one end. Excludes BIT, SCREWDRIVER. View more Socket Wrench Screwdriver Attachment
May 2023
10
Marketplace 5120-01-399-9821
Request a Quotation from participating marketplace vendors
Related Documents 5120-01-399-9821 1+ Documents (More...)
Photo 1/4 5120-01-399-9821 Photo 2/4 5120-01-399-9821 Photo 3/4 NSN 5120-01-399-9821 (Identification
NE Updated Every Day 4990-5MXL RQST NE Updated Every Day 1AL87 RQST NE Updated Every Day 5120-01-399
Restrictions 5120-01-399-9821
5120-01-399-9821 is a Socket Wrench Screwdriver Attachment that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-399-9821
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-399-9821
- Republic of Korea (ZH01)
- Effective Date:
- 1 Aug 2012
Approved Sources 5120-01-399-9821
- Part Number
- Manufacturer
- Status
- J4990-5MXL
- Manufacturer
- 1CV05 - The Stanley Works (Active)
- Primary Buy
- Primary Buy
- 1AL87
- 25795 - W.W. Grainger, Inc. (Active)
- Secondary Buy
- Secondary Buy
- 4990-5MXL
- 1CV05 - The Stanley Works (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-01-399-9821
- Characteristic
- Specifications
- FIIG
- Specifications
- A102A0
- Material [MATT]
- Steel Overall
- Surface Treatment [SFTT]
- Chromium Overall
- Style Designator [STYL]
- Hexagon
- Overall Length [ABHP]
- 154.8 Millimeters Nominal
- Blade Length [AEAE]
- 127.0 Millimeters Nominal
- Wrenching Surface Size [AJBR]
- 5.0 Millimeters Nominal Single End
- Wrenching Surface Shape [CRWY]
- Hexagon Single End External
- Drive Surface Size [ATNC]
- 0.375 Inches Nominal Single End
- Features Provided [CBBL]
- Manual Tool
Similar Supply Items to 5120-01-399-9821
Freight Information 5120-01-399-9821
5120-01-399-9821 has freight characteristics.. 5120-01-399-9821 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
