5120-01-399-9539
Socket Wrench Socket
5120013999539 013999539 B107.5 B107.5 TY1CL1 J4708M 1AH19 4708M
An item having an internal drive at one end made to fit into the external drive end of a socket wrench handle, torque wrench, or power driven tool. The opposite end consists of various internal wrench shapes such as hexagon or square. It may include an integral universal joint. View more Socket Wrench Socket
May 2023
13
Marketplace 5120-01-399-9539
Request a Quotation from participating marketplace vendors
Related Documents 5120-01-399-9539 5+ Documents (More...)
SOCKET,SOCKET WRENCH 10 EA NS Request Quotation Updated Every Day J4708M RQST NE Updated Every Day 4708M
RQST NE Updated Every Day 1AH19 RQST NE Updated Every Day 5120-01-399-9539 RQST NE Updated Every Day
Socket Wrench Socket 5120013999539 013999539 Account Upgrade 5120-01-399-9539Socket Wrench Socket5120013999539
013999539 B107.5 B107.5 TY1CL1 J4708M to View Vendor Details... 4708M SOCKET,SOCKET WRENCH 10 EA NS
NE Updated Every /fsg-51/fsc-5120/us 5120-01-113-9557 Socket Wrench Socket 5120011139557 011139557 B107.5
www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-113-9557 Socket Wrench Socket 5120011139557 011139557 B107.5
//www.nsnlookup.com /fsg-53/fsc-5360/us 5360-00-920-0030 Compression Helical Spring 5360009200030 B107.5
www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-112-0579 Socket Wrench Socket 5120011120579 011120579 B107.5
TY1CL1 B107.5M TY1CL1 B107.5M CL1STAB107.5M A group of SOCKET, SOCKET WRENCH having different B107.5
TY1CL1 V610MMR V610MM An item having an internal drive at one end made to fit into the external B107.5
Restrictions 5120-01-399-9539
5120-01-399-9539 is a Socket Wrench Socket that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-399-9539
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-399-9539
- US Army (A192)
- Effective Date:
- 9 Jan 1995
- US Coast Guard (C014)
- Effective Date:
- 9 Jan 1995
- US Air Force (FGGS)
- Effective Date:
- 9 Jan 1995
- NASA (G751)
- Effective Date:
- 7 Dec 1994
- US Marine Corps (MC14)
- Effective Date:
- 9 Jan 1995
- Republic of Korea (ZH01)
- Effective Date:
- 1 Jun 2012
Approved Sources 5120-01-399-9539
- Part Number
- Manufacturer
- Status
- B107.5
- Manufacturer
- 05047 - The American Society Of Mechanical (Active)
- Incomplete Reference
- Incomplete Reference
- B107.5 TY1CL1
- 80244 - General Services Administration (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- J4708M
- 1CV05 - The Stanley Works (Active)
- Secondary Buy
- Secondary Buy
- 1AH19
- 25795 - W.W. Grainger, Inc. (Active)
- Secondary Buy
- Secondary Buy
- 4708M
- 1CV05 - The Stanley Works (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-01-399-9539
- Characteristic
- Specifications
- FIIG
- Specifications
- A102A0
- Drive End Shape [CTCT]
- Square Single End Internal
- Drive Surface Size [ATNC]
- 0.250 Inches Nominal Single End
- Features Provided [CBBL]
- Manual Tool
- Material [MATT]
- Steel Overall
- Nondefinitive Spec/Std Data [ZZZT]
- 1 Type And 1 Class
- Overall Length [ABHP]
- 26.0 Millimeters Maximum
- Wrenching Surface Shape [CRWY]
- 6 Point Single End Internal
- Wrenching Surface Size [AJBR]
- 8.0 Millimeters Nominal Single End
- Specification/Standard Data [ZZZK]
- 05047-Asme B107.5 Professional/Industrial Association Standard
- Style Designator [STYL]
- Internal-Internal
- Surface Treatment [SFTT]
- Chromium Overall
Management Data 5120-01-399-9539
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Feb 2023
- General Services Administration (TG)
- EA
- Subscribe
- EA
NATO Stock Numbers Related to 5120-01-399-9539
Freight Information 5120-01-399-9539
5120-01-399-9539 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186620. A Sub NMFC of Z. It has a NMFC Description of TOOLS, NOI HAND OTHER THAN POWER. 5120-01-399-9539 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5120-01-399-9539 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5120-01-399-9539 is not classified as a special type of cargo when transported by water. 5120-01-399-9539 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
