5120-01-399-9025
Torque Wrench
5120013999025 013999025 B107.300 B107.14 B107.14 TY2CLAST2DEA 4YA76 J6072C 1ARL9 6072C 6072 6072B
A manual tool for tightening various fasteners to a precise torque value. Consists of a handle and drive to accommodate female square drive sockets and other types of wrenching adapters. Torque value may be manually set and adjusted by user or may be provided as preset for production line use. A signaling device is generally provided to indicate when set torque value is reached. Handle is swung at right angle to axis of fastener rotation to apply torque. For items with handles that are spun in-line with axis of fastener rotation to apply torque, see SCREWDRIVER, TORQUE. View more Torque Wrench
Managed by United States
NSN Created on 7 Dec 1994
Data Last Changed
May 2023
May 2023
NATO Update Count
25
25
NATO Data Quality
Marketplace 5120-01-399-9025
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Updated Every Day J6072C RQST NE
Updated Every Day 6072C RQST NE
Updated Every Day 6072 RQST NE
Updated Every Day 6072B RQST NE
Updated Every Day 4YA76 RQST NE
Updated Every Day 1ARL9 RQST NE
Updated Every Day 5120-01-399-9025 RQST NE
Updated Every Day 5120-01-399-9025 RQST
Updated Every Day 5120-01-399-9025 RQST NE
Related Documents 5120-01-399-9025 5+ Documents (More...)
B107.300 B107.14 B107.14 TY2CLAST2DEA 4YA76 J6072C 1ARL9 6072C 6072 6072B A manual tool for tightening
6072 RQST NE Updated Every Day 6072B RQST NE Updated Every Day 4YA76 RQST NE Updated Every Day 1ARL9
A manual tool for tightening 6072 RQST NE Updated Every Day 6072B RQST NE Updated Every Day 4YA76 RQST
6072 RQST NE Updated Every Day 6072B RQST NE Updated Every Day 4YA76 RQST NE Updated Every Day 1ARL9
A manual tool for tightening 6072 RQST NE Updated Every Day 6072B RQST NE Updated Every Day 4YA76 RQST
Porte2540152215757 152215757 6072B Managed by Italy NSN Created on 16 Nov 2005 Data Last Changed January
Torque Wrench 5120013999025 013999025 Wrench5120013999025 013999025 B107.300 B107.14 B107.14 TY2CLAST2DEA
4YA76 J6072C 1ARL9 6072C 6072 6072B Vendor Details... 6072 WRENCH,TORQUE RQST NS Request Quotation Subscribe
Torque Wrench 5120013999025 013999025 Wrench5120013999025 013999025 B107.300 B107.14 B107.14 TY2CLAST2DEA
4YA76 J6072C 1ARL9 6072C 6072 6072B Vendor Details... 6072 WRENCH,TORQUE RQST NS Request Quotation Subscribe
2005 Data Last Changed January 6072B Vendor Details... 6072 WRENCH,TORQUE RQST NS Request Quotation
Subscribe to View Vendor Details ... 6072B Day J6072C RQST NE Updated Every Day 6072C RQST NE Updated
5120013999025 013999025 6072B A manual tool for tightening various fasteners to a precise torque value
Subscribe to View Vendor Details ... 6072B Day J6072C RQST NE Updated Every Day 6072C RQST NE Updated
5120013999025 013999025 6072B A manual tool for tightening various fasteners to a precise torque value
TY2CLAST2DEA TY1CL2 QJR3200A B107.14 TY2CLAST2DEA QJR3200 QJR3200B https//www.nsnlookup.com B107.14
5120014394398014394398 QJR3200A B107.14 TY2CLAST2DEA QJR3200 QJR3200B TY1CL2 AS28431 QJR3200A B107.14
B107.14 TY2CLAST2DEA QJR3200 B107.14 TY2CLAST2DEA TY1CL2 AS28431 TY2CLAST2DEA QJR3200 QJR3200B B107.14
5120014394398014394398 QJR3200A B107.14 TY2CLAST2DEA QJR3200 QJR3200B TY1CL2 AS28431 QJR3200A B107.14
B107.14 TY2CLAST2DEA QJR3200 B107.14 TY2CLAST2DEA TY1CL2 AS28431 TY2CLAST2DEA QJR3200 QJR3200B B107.14
QJR3200B B107.14 TY2CLAST2DEA https// B107.14 011255190 TY1CL2 AS28431 QJR3200A B107.14 TY2CLAST2DEA
TY2CLAST2DEA QJR3200 QJR3200B TY1CL2 AS28431 QJR3200A B107.14 B107.14 TY2CLAST2DEA QJR3200 B107.14 TY2CLAST2DEA
QJR3200A B107.14 TY2CLAST2DEA QJR3200 B107.14 TY2CLAST2DEA TY1CL2 AS28431 QJR3200A B107.14 A manual
TY2CLAST2DEA QJR3200 QJR3200B TY1CL2 AS28431 QJR3200A B107.14 B107.14 TY2CLAST2DEA QJR3200 B107.14 TY2CLAST2DEA
QJR3200A B107.14 TY2CLAST2DEA QJR3200 B107.14 TY2CLAST2DEA TY1CL2 AS28431 QJR3200A B107.14 A manual
Restrictions 5120-01-399-9025
5120-01-399-9025 is a Torque Wrench that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-399-9025
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-399-9025
- US Army (A192)
- Effective Date:
- 1 Jan 1995
- US Coast Guard (C014)
- Effective Date:
- 1 Jan 1995
- US Air Force (FGGS)
- Effective Date:
- 1 Jan 1995
- NASA (G751)
- Effective Date:
- 1 Dec 1994
- US Marine Corps (MC14)
- Effective Date:
- 1 Jan 1995
- US Navy (N9QG)
- Effective Date:
- 1 Jan 2014
- Supplementary Collaborators:
- GG
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1995
- Denmark (ZS01)
- Effective Date:
- 1 Oct 1997
Approved Sources 5120-01-399-9025
- Part Number
- Manufacturer
- Status
- B107.300
- Manufacturer
- 05047 - The American Society Of Mechanical (Active)
- Incomplete Reference
- Incomplete Reference
- B107.14
- 05047 - The American Society Of Mechanical (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- B107.14 TY2CLAST2DEA
- 80244 - General Services Administration (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 4YA76
- 25795 - W.W. Grainger, Inc. (Active)
- Secondary Buy
- Secondary Buy
- J6072C
- 1CV05 - The Stanley Works (Active)
- Secondary Buy
- Secondary Buy
- 1ARL9
- 25795 - W.W. Grainger, Inc. (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 6072C
- 1CV05 - The Stanley Works (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 6072
- 1CV05 - The Stanley Works (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 6072B
- 1CV05 - The Stanley Works (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-01-399-9025
- Characteristic
- Specifications
- FIIG
- Specifications
- A102A0
- Drive End Shape [CTCT]
- Square Single End External
- Drive Surface Size [ATNC]
- 0.500 Inches Nominal Single End
- Furnished Items [AFJH]
- Case
- Material [MATT]
- Steel Overall
- Nondefinitive Spec/Std Data [ZZZT]
- 2 Type And A Class And 2 Style And A Design
- Overall Length [ABHP]
- 26.250 Inches Nominal
- Special Features [FEAT]
- Ratchet Head; Plain Steel Handle; Dual Scale; 11.5 Cmkg Graduations
- Torque Scale Graduation [AJCH]
- 10.00 Inch-Pounds
- Torque Signal Method [AJDR]
- Audible
- Torque Capacity [AJCG]
- 600.0 Inch-Pounds Minimum And 3000.0 Inch-Pounds Maximum And 749.0 Centimeter-Kilograms Minimum And 3514.0 Centimeter-Kilograms Maximum
- Torque Indicating Mechanism [AJCF]
- Micrometer
- Specification/Standard Data [ZZZK]
- 05047-Asme B107.300 Professional/Industrial Association Standard
- Style Designator [STYL]
- Micrometer End Drive
- Surface Treatment [SFTT]
- Chromium Overall
Management Data 5120-01-399-9025
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Feb 2020
- Department of the Air Force (DF)
- EA
- Subscribe
- EA
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- D
- Durable item.An item of Army property coded with an ARC of D in the AMDF. Durable items do not require property book accountability after issue from the stock record account but do require hand receipt control when issued to the user. Commercial and fabricated items similar to items coded D in the AMDF are considered durable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9Q
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- 02
- Operational Test:
- No Special Procedures
NATO Stock Numbers Related to 5120-01-399-9025
5120-66-154-5290 5120-12-384-3257 5120-25-135-7395 5120-21-870-1566 5120-12-312-4120 5120-99-433-0354 5120-99-788-6215 5120-99-122-6175 5120-22-125-4799 5120-34-030-0586 5120-12-345-4269 5120-12-367-1978 5120-99-258-1646 5120-99-108-9853 5120-99-738-9953 5120-22-309-1479 5120-21-880-8042 5120-99-739-0718
Freight Information 5120-01-399-9025
5120-01-399-9025 has freight characteristics.. 5120-01-399-9025 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
