5120-01-397-2966
Socket Wrench Extension
5120013972966 013972966 10-921 A10-921
An attachment for extending the drive length of socket wrenches or handles. The body of the item may be either a coil spring or a solid bar. The items permit the connection of ends that are designed for direct mating to each other. See also ADAPTER, SOCKET WRENCH; UNIVERSAL JOINT, SOCKET WRENCH ATTACHMENT; and ADAPTER, SOCKET, CROWFOOT SOCKET WRENCH HEAD. View more Socket Wrench Extension
May 2023
13
Marketplace 5120-01-397-2966
Request a Quotation from participating marketplace vendors
Related Documents 5120-01-397-2966 1+ Documents (More...)
5120-01-397-2966 RQST NE Updated Every Day 5120-01-397-2966 RQST Updated Every Day 5120-01-397-2966
Photo 1/2 NSN 5120-01-397-2966 (Identification) 2/2 - - 1. 5120-01-397-2966 RQST NE Updated Every Day
Restrictions 5120-01-397-2966
5120-01-397-2966 is a Socket Wrench Extension that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-397-2966
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-397-2966
- Singapore (YJ01)
- Effective Date:
- 1 Jul 1999
- Australia (ZA01)
- Effective Date:
- 1 Sep 2009
- Denmark (ZS01)
- Effective Date:
- 1 Jul 2005
Approved Sources 5120-01-397-2966
- Part Number
- Manufacturer
- Status
- 10-921
- Manufacturer
- 636D0 - Apex Tool Group, Llc (Active)
- Primary Buy
- Primary Buy
- A10-921
- Z19N0 - The Trustee For Henchman Unit Trust (Active)
- Secondary Buy
- Secondary Buy
- 10-921
- 08292 - Easco Hand Tools Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 10-921
- 03914 - Armstrong Bros Tool Co (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- A10-921
- ZAE87 - Henchman Products Pty Ltd (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-01-397-2966
- Characteristic
- Specifications
- FIIG
- Specifications
- A102A0
- Material [MATT]
- Steel Overall
- Surface Treatment [SFTT]
- Chromium Overall
- Style Designator [STYL]
- Rigid
- Overall Length [ABHP]
- 2.000 Inches Nominal
- Drive Surface Size [ATNC]
- 0.250 Inches Nominal Both Ends
- Drive End Shape [CTCT]
- Square First End Internal
- Drive End Shape [CTCT]
- Square Second End External
- Features Provided [CBBL]
- Manual Tool
Similar Supply Items to 5120-01-397-2966
Freight Information 5120-01-397-2966
5120-01-397-2966 has freight characteristics.. 5120-01-397-2966 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
