5120-01-367-3205
Socket Wrench Socket
5120013673205 013673205 B107.5 B107.5 TY1CL1 39-027
An item having an internal drive at one end made to fit into the external drive end of a socket wrench handle, torque wrench, or power driven tool. The opposite end consists of various internal wrench shapes such as hexagon or square. It may include an integral universal joint. View more Socket Wrench Socket
Managed by United States
NSN Created on 10 Nov 1992
Data Last Changed
November 2023
November 2023
NATO Update Count
21
21
NATO Data Quality
Marketplace 5120-01-367-3205
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
FedMall
Updated Every 15 Minutes
Updated Every 15 Minutes 5120-01-367-3205 BUY NE FedMall
Updated Every Day 39-027 RQST NE
Updated Every Day 5120-01-367-3205 RQST NE
Updated Every Day 5120-01-367-3205 RQST
Updated Every Day 5120-01-367-3205 RQST NE
Related Documents 5120-01-367-3205 5+ Documents (More...)
B107.5 B107.5 TY1CL1 39-027 An item having an internal drive at one end made to fit into the external
BUY NE FedMall Updated Every Day 39-027 RQST NE Updated Every Day 5120-01-367-3205 RQST NE Updated Every
Wrench Socket 5120011128318 011128318 B107.5 TY1CL1 An item having https//www.nsnlookup.com /fsg-51/
BUY NE FedMall Updated Every Day 39-027 RQST NE Updated Every Day 5120-01-367-3205 RQST NE Updated Every
Wrench Socket 5120011128318 011128318 B107.5 TY1CL1 An item having https//www.nsnlookup.com /fsg-51/
B107.5 TY1CL1 An item having an internal drive at one end made to fit into the external drive end of
www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-366-9134 Socket Wrench Socket 5120013669134 013669134 B107.5
TY1CL1 V610MMR V610MM An item having an internal drive at one end made to fit into the external B107.5
www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-366-9134 Socket Wrench Socket 5120013669134 013669134 B107.5
TY1CL1 V610MMR V610MM An item having an internal drive at one end made to fit into the external B107.5
B107.5 TY1CL1 J5419MH 5F464 5419MH An item having an internal drive at one end made to fit into the
www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-112-8318 Socket Wrench Socket 5120011128318 011128318 B107.5
www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-428-4956 Socket Wrench Socket 5120014284956014284956 013669134 B107.5
www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-112-8318 Socket Wrench Socket 5120011128318 011128318 B107.5
www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-428-4956 Socket Wrench Socket 5120014284956014284956 013669134 B107.5
B107.5 TY1CL1 TWM27 D016027 ZHVY0295 39-027 An item having an internal drive at one end made to fit
RQST NE Updated Every Day 5120-01 011024471 B107.5 TY1CL1 26070-9 An item having https//www.nsnlookup.com
Socket Wrench Socket 5120013673205 013673205 B107.5 TY1CL139-027 An item having an internal drive
RQST NE Updated Every Day 5120-01 011024471 B107.5 TY1CL1 26070-9 An item having https//www.nsnlookup.com
Socket Wrench Socket 5120013673205 013673205 B107.5 TY1CL139-027 An item having an internal drive
B107.5 TY1CL1 TWM27 D016027 ZHVY0295 39-027 An item having an internal drive at one end made to fit
Every Day 5120-01 https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-367-3205 Socket Wrench Socket
5120013673205 013673205 www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-348-9046 Socket Wrench Socket
Every Day 5120-01 https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-367-3205 Socket Wrench Socket
5120013673205 013673205 www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-348-9046 Socket Wrench Socket
Restrictions 5120-01-367-3205
5120-01-367-3205 is a Socket Wrench Socket that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 5120-01-367-3205
- US Army (A192)
- Effective Date:
- 1 May 2011
- Supplementary Receivers:
- BF
- NASA (G751)
- Effective Date:
- 1 May 2011
- NASA (G752)
- Effective Date:
- 1 Feb 2005
- US Navy (N9QG)
- Effective Date:
- 1 Jan 2014
- Supplementary Collaborators:
- GG
- Canada (ZC01)
- Effective Date:
- 1 Feb 2007
Approved Sources 5120-01-367-3205
- Part Number
- Manufacturer
- Status
- B107.5
- Manufacturer
- 05047 - The American Society Of Mechanical (Active)
- Incomplete Reference
- Incomplete Reference
- B107.5 TY1CL1
- 80244 - General Services Administration (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 39-027
- 08292 - Easco Hand Tools Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 39-027
- 636D0 - Apex Tool Group, Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 39-027
- 03914 - Armstrong Bros Tool Co (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-01-367-3205
- Characteristic
- Specifications
- Drive End Outside Diameter [AHMK]
- Specifications
- 36.75 Millimeters Maximum
- Drive End Shape [CTCT]
- Square Single End Internal
- Drive Surface Size [ATNC]
- 0.500 Inches Nominal Single End
- Features Provided [CBBL]
- Manual Tool
- Material [MATT]
- Steel Overall
- Nondefinitive Spec/Std Data [ZZZT]
- 1 Type And 1 Class
- Overall Length [ABHP]
- 48.0 Millimeters Maximum
- Wrenching End Outside Diameter [AHMJ]
- 36.75 Millimeters Maximum
- Wrenching Surface Shape [CRWY]
- 6 Point Single End Internal
- Wrenching Surface Size [AJBR]
- 27.0 Millimeters Nominal Single End
- Wrenching End Opening Depth [AJAP]
- 15.80 Millimeters Minimum
- Specification/Standard Data [ZZZK]
- 05047-Asme B107.5 Professional/Industrial Association Standard
- Style Designator [STYL]
- Internal-Internal
- Surface Treatment [SFTT]
- Chromium Overall
Management Data 5120-01-367-3205
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9Q
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- 02
- Operational Test:
- 0
- Physical Category:
- 1
- Bin
NATO Stock Numbers Related to 5120-01-367-3205
5120-14-210-9852 5120-12-364-6803 5120-98-205-9462 5120-33-155-9422 5120-15-113-2845 5120-37-504-7952 5130-21-808-0702 5120-33-110-6240 5120-27-047-5375 5120-14-484-6515 5120-99-786-2481 5120-14-200-9336 5120-14-548-5093 5120-14-530-5337 5120-14-442-2003 5120-34-041-3160 5120-14-525-4363 5120-99-755-3201
Freight Information 5120-01-367-3205
5120-01-367-3205 has freight characteristics.. 5120-01-367-3205 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
