5120-01-361-0200
Combination Box And Open End Wrench
5120013610200 013610200 1136
A nonadjustable wrench having a box wrenching feature on one end and an open end wrenching feature on the other end. Excludes WRENCH, BOX and WRENCH, OPEN END. View more Combination Box And Open End Wrench
November 2023
9
Marketplace 5120-01-361-0200
Request a Quotation from participating marketplace vendors
Related Documents 5120-01-361-0200 2+ Documents (More...)
Updated Every Day 5120-01-361-0200 RQST NE Related Documents 5120-01-361-0200 1+ Documents ( More...
1136 BUY NE FedMall Updated Every Day 5120-01-361-0200 RQST NE Updated Every Day 5120-01-361-0200 RQST
Restrictions 5120-01-361-0200
5120-01-361-0200 is a Combination Box And Open End Wrench that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 5120-01-361-0200
- NASA (G752)
- Effective Date:
- 1 Oct 2010
Approved Sources 5120-01-361-0200
- Part Number
- Manufacturer
- Status
- 1136
- Manufacturer
- 79808 - Wright Tool Co (Active)
- Primary Buy
- Primary Buy
Datasheet 5120-01-361-0200
- Characteristic
- Specifications
- Material [MATT]
- Specifications
- Steel Overall
- Surface Treatment [SFTT]
- Chromium Overall
- Style Designator [STYL]
- Offset
- Overall Length [ABHP]
- 14.969 Inches Nominal
- Head Angle [CRCS]
- 15.0 Degrees Nominal
- Wrenching End Offset Angle [CSPX]
- 15.0 Degrees Nominal
- Wrenching Surface Size [AJBR]
- 1.125 Inches Nominal Both Ends
- Wrenching Surface Shape [CRWY]
- Oval First End Internal
- Wrenching Surface Shape [CRWY]
- 12 Point Second End Internal
- Special Features [FEAT]
- Flat Stem
Management Data 5120-01-361-0200
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Jun 2014
- US Marine Corps (DM)
- EA
- Subscribe
- EA
- Dec 2007
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- Nov 2000
- Department of the Army (DA)
- EA
- Subscribe
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Navy (DN)
- N
- V
- Discontinued Without Replacement
- V
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- D
- Durable item.An item of Army property coded with an ARC of D in the AMDF. Durable items do not require property book accountability after issue from the stock record account but do require hand receipt control when issued to the user. Commercial and fabricated items similar to items coded D in the AMDF are considered durable items.
Navy
- Cognizance:
- 9Q
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 7
- Reviewed and determined non-essential
- Echelon Management:
- 02
- Operational Test:
- No Special Procedures
Similar Supply Items to 5120-01-361-0200
Freight Information 5120-01-361-0200
5120-01-361-0200 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186710. A Sub NMFC of Z. It has a NMFC Description of TOOLS:TORCHES HAND O/T BLOW. 5120-01-361-0200 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5120-01-361-0200 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5120-01-361-0200 is not classified as a special type of cargo when transported by water. 5120-01-361-0200 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
