5120-01-361-0182
Socket Wrench Extension
5120013610182 013610182 2404
An attachment for extending the drive length of socket wrenches or handles. The body of the item may be either a coil spring or a solid bar. The items permit the connection of ends that are designed for direct mating to each other. See also ADAPTER, SOCKET WRENCH; UNIVERSAL JOINT, SOCKET WRENCH ATTACHMENT; and ADAPTER, SOCKET, CROWFOOT SOCKET WRENCH HEAD. View more Socket Wrench Extension
November 2023
8
Marketplace 5120-01-361-0182
Request a Quotation from participating marketplace vendors
Related Documents 5120-01-361-0182 3+ Documents (More...)
Every Day 5120-01-361-0182 RQST NE Updated Every Day 5120-01-361-0182 RQST Updated Every Day 5120-01-
/fsg-51/fsc-5120/us 5120-01-361-0182 Socket Wrench Extension 5120013610182,2404 2404 An attachment for
Restrictions 5120-01-361-0182
5120-01-361-0182 is a Socket Wrench Extension that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 5120-01-361-0182
- NASA (G752)
- Effective Date:
- 1 Oct 2010
Approved Sources 5120-01-361-0182
- Part Number
- Manufacturer
- Status
- 2404
- Manufacturer
- 79808 - Wright Tool Co (Active)
- Primary Buy
- Primary Buy
Datasheet 5120-01-361-0182
- Characteristic
- Specifications
- Material [MATT]
- Specifications
- Steel Overall
- Surface Treatment [SFTT]
- Chromium Overall
- Style Designator [STYL]
- Rigid
- Overall Length [ABHP]
- 4.000 Inches Nominal
- Drive Surface Size [ATNC]
- 0.250 Inches Nominal Both Ends
- Drive End Shape [CTCT]
- Square First End Internal
- Drive End Shape [CTCT]
- Square Second End External
- Features Provided [CBBL]
- Manual Tool
Management Data 5120-01-361-0182
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Dec 2007
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- Nov 2000
- Department of the Army (DA)
- EA
- Subscribe
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Navy (DN)
- N
- V
- Discontinued Without Replacement
- V
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9Q
Similar Supply Items to 5120-01-361-0182
Freight Information 5120-01-361-0182
5120-01-361-0182 has freight characteristics.. 5120-01-361-0182 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
