5120-01-349-1496
Combination Box And Open End Wrench
5120013491496 013491496 11-22MM
A nonadjustable wrench having a box wrenching feature on one end and an open end wrenching feature on the other end. Excludes WRENCH, BOX and WRENCH, OPEN END. View more Combination Box And Open End Wrench
May 2023
11
Marketplace 5120-01-349-1496
Request a Quotation from participating marketplace vendors
Related Documents 5120-01-349-1496 3+ Documents (More...)
5120-01-349-1496 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-349-1496
Combination Box And Open End Wrench,11-22MM NE Updated Every Day 5120-01-349-1496 RQST Updated Every
Restrictions 5120-01-349-1496
5120-01-349-1496 is a Combination Box And Open End Wrench that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-349-1496
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-349-1496
- Denmark (ZS01)
- Effective Date:
- 1 Feb 2005
Approved Sources 5120-01-349-1496
- Part Number
- Manufacturer
- Status
- 11-22MM
- Manufacturer
- 79808 - Wright Tool Co (Active)
- Primary Buy
- Primary Buy
Datasheet 5120-01-349-1496
- Characteristic
- Specifications
- FIIG
- Specifications
- A527Y0
- Material [MATT]
- Steel Overall
- Surface Treatment [SFTT]
- Chromium Overall
- Style Designator [STYL]
- Offset
- Overall Length [ABHP]
- 11.219 Inches Nominal
- Head Angle [CRCS]
- 15.0 Degrees Nominal
- Wrenching End Offset Angle [CSPX]
- 15.0 Degrees Nominal
- Wrenching Surface Size [AJBR]
- 22.0 Millimeters Nominal Both Ends
- Wrenching Surface Shape [CRWY]
- Oval First End Internal
- Wrenching Surface Shape [CRWY]
- 12 Point Second End Internal
- Special Features [FEAT]
- Flat Stem
Similar Supply Items to 5120-01-349-1496
Freight Information 5120-01-349-1496
5120-01-349-1496 has freight characteristics.. 5120-01-349-1496 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
