5120-01-349-1494
Combination Box And Open End Wrench
5120013491494 013491494 11-20MM
A nonadjustable wrench having a box wrenching feature on one end and an open end wrenching feature on the other end. Excludes WRENCH, BOX and WRENCH, OPEN END. View more Combination Box And Open End Wrench
May 2023
11
Marketplace 5120-01-349-1494
Request a Quotation from participating marketplace vendors
Related Documents 5120-01-349-1494 3+ Documents (More...)
Combination Box And Open End Wrench,11-20MM Photo 1/3 5120-01-349-1494 Photo 2/3 NSN 5120-01-349-1494
NE Updated Every Day 5120-01-349-1494 RQST Updated Every Day 5120-01-349-1494 RQST NE Related Documents
www.nsnlookup.com /fsg-48/fsc-4820/uk 4820-99-787-1137 https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-349-1494
Combination Box And Open End Wrench,11-20MM www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-349-1494
/fsg-51/fsc-5120/uk 5120-99-537-1070 Wedge 5120995371070995371070 002522358SH03002522358044002213/11(20MM
537-1070Wedge5120995371070 995371070002522358SH03 https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-349-1494
Restrictions 5120-01-349-1494
5120-01-349-1494 is a Combination Box And Open End Wrench that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-349-1494
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-349-1494
- Denmark (ZS01)
- Effective Date:
- 1 Feb 2005
Approved Sources 5120-01-349-1494
- Part Number
- Manufacturer
- Status
- 11-20MM
- Manufacturer
- 79808 - Wright Tool Co (Active)
- Primary Buy
- Primary Buy
Datasheet 5120-01-349-1494
- Characteristic
- Specifications
- FIIG
- Specifications
- A527Y0
- Material [MATT]
- Steel Overall
- Surface Treatment [SFTT]
- Chromium Overall
- Style Designator [STYL]
- Offset
- Overall Length [ABHP]
- 9.781 Inches Nominal
- Head Angle [CRCS]
- 15.0 Degrees Nominal
- Wrenching End Offset Angle [CSPX]
- 15.0 Degrees Nominal
- Wrenching Surface Size [AJBR]
- 20.0 Millimeters Nominal Both Ends
- Wrenching Surface Shape [CRWY]
- Oval First End Internal
- Wrenching Surface Shape [CRWY]
- 12 Point Second End Internal
- Special Features [FEAT]
- Flat Stem
Similar Supply Items to 5120-01-349-1494
Freight Information 5120-01-349-1494
5120-01-349-1494 has freight characteristics.. 5120-01-349-1494 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
