5120-01-348-1960
Box Wrench
5120013481960 013481960 JHD110M HD110M
A nonadjustable wrench having a box wrenching feature on one or both ends. Excludes WRENCH, OPEN END BOX; and WRENCH, BOX AND OPEN END, COMBINATION. View more Box Wrench
May 2023
4
Marketplace 5120-01-348-1960
Request a Quotation from participating marketplace vendors
Related Documents 5120-01-348-1960 1+ Documents (More...)
Photo 1/3 5120-01-348-1960 Photo 2/3 NSN 5120-01-348-1960 (Identification) 3/3 - - - 1.
HD110M WRENCH,BOX 10 EA NS Request Quotation Subscribe to View Vendor Details... 5120-01-348-1960 WRENCH
Restrictions 5120-01-348-1960
5120-01-348-1960 is a Box Wrench that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-348-1960
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-348-1960
- NASA (G751)
- Effective Date:
- 1 Apr 1991
- US Navy (N9QG)
- Effective Date:
- 1 Apr 1991
- Supplementary Collaborators:
- HD
Approved Sources 5120-01-348-1960
- Part Number
- Manufacturer
- Status
- JHD110M
- Manufacturer
- 1CV05 - The Stanley Works (Active)
- Primary Buy
- Primary Buy
- HD110M
- 1CV05 - The Stanley Works (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-01-348-1960
- Characteristic
- Specifications
- FIIG
- Specifications
- A527Y0
- Material [MATT]
- Steel Overall
- Surface Treatment [SFTT]
- Oxide Overall
- Style Designator [STYL]
- Slugging
- Overall Length [ABHP]
- 502.0 Millimeters Nominal
- Outside Diameter [ABKV]
- 165.0 Millimeters Nominal
- Head Thickness [AHML]
- 76.0 Millimeters Nominal
- Wrenching Surface Size [AJBR]
- 110.0 Millimeters Nominal Single End
- Wrenching Surface Shape [CRWY]
- 12 Point Single End Internal
Management Data 5120-01-348-1960
Navy
- Cognizance:
- 9Q
Similar Supply Items to 5120-01-348-1960
Freight Information 5120-01-348-1960
5120-01-348-1960 has freight characteristics managed by the Food and Drug Administration (FDA).It has a National Motor Freight Classification (NMFC) of 186620. A Sub NMFC of Z. It has a NMFC Description of TOOLS, NOI HAND OTHER THAN POWER. 5120-01-348-1960 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5120-01-348-1960 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5120-01-348-1960 is not classified as a special type of cargo when transported by water. 5120-01-348-1960 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
