5120-01-335-9090
Socket Wrench Socket
5120013359090 013359090 AS954 AS954 TY1CL1STA 6170
An item having an internal drive at one end made to fit into the external drive end of a socket wrench handle, torque wrench, or power driven tool. The opposite end consists of various internal wrench shapes such as hexagon or square. It may include an integral universal joint. View more Socket Wrench Socket
May 2023
12
Marketplace 5120-01-335-9090
Request a Quotation from participating marketplace vendors
Related Documents 5120-01-335-9090 5+ Documents (More...)
AS954 SOCKET,SOCKET WRENCH 300 EA NS Request Quotation Subscribe to View Vendor Details... 6170 SOCKET
AS954 SOCKET,SOCKET WRENCH 6 EA NS Request Quotation Subscribe to View Vendor Details... 5120-01-335-
AS954 SOCKET,SOCKET WRENCH 1 EA NS Request Quotation Subscribe to View Vendor Details...
AS954 SOCKET,SOCKET WRENCH 300 EA NS Request Quotation Subscribe to View Vendor Details...
Socket Wrench Socket 5120013359090 013359090 /fsg-51/fsc-5120/us 5120-01-335-0805 Socket Wrench
Socket 5120013350805 013350805 AS954 TY1CL1STA SW341 11A7000792-11FRS SW341 An item having an internal
www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-518-4492 Socket Wrench Socket 5120015184492 015184492 AS954
www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-437-2048 Socket Wrench Socket 5120014372048 014372048 AS954
B107.5MB107.5M https//www.nsnlookup.com /fsg-51/fsc TY1CL1STAB107.5M An item having AS954 TY1CL1STA
AS954 TY1CL1STA https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120- https//www.nsnlookup.com /fsg-51/
Restrictions 5120-01-335-9090
5120-01-335-9090 is a Socket Wrench Socket that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-335-9090
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-335-9090
- US Army (A192)
- Effective Date:
- 1 Apr 1991
- Supplementary Receivers:
- CT
- US Air Force (FGGS)
- Effective Date:
- 1 Apr 1991
- NASA (G751)
- Effective Date:
- 1 Apr 1991
- US Marine Corps (MC14)
- Effective Date:
- 1 Apr 1991
- US Navy (N9QG)
- Effective Date:
- 1 Jun 2004
- Turkey (ZW01)
- Effective Date:
- 1 Dec 2005
Approved Sources 5120-01-335-9090
- Part Number
- Manufacturer
- Status
- AS954
- Manufacturer
- 0U583 - Sae International (Active)
- Incomplete Reference
- Incomplete Reference
- AS954 TY1CL1STA
- 80244 - General Services Administration (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 6170
- 79808 - Wright Tool Co (Active)
- Secondary Buy
- Secondary Buy
- AS954
- 81343 - Society Of Automotive Engineers Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-01-335-9090
- Characteristic
- Specifications
- FIIG
- Specifications
- A102A0
- Drive End Shape [CTCT]
- Square Single End Internal
- Drive Surface Size [ATNC]
- 0.750 Inches Nominal Single End
- Features Provided [CBBL]
- Manual Tool
- Material [MATT]
- Steel Overall
- Nondefinitive Spec/Std Data [ZZZT]
- 1 Type And 1 Class And A Style
- Overall Length [ABHP]
- 3.062 Inches Nominal
- Wrenching Surface Shape [CRWY]
- 12 Point Single End Internal
- Wrenching Surface Size [AJBR]
- 2.188 Inches Nominal Single End
- Specification/Standard Data [ZZZK]
- 81343-Sae As954 Professional/Industrial Association Standard
- Style Designator [STYL]
- Internal-Internal
- Surface Treatment [SFTT]
- Chromium Overall
Similar Supply Items to 5120-01-335-9090
Freight Information 5120-01-335-9090
5120-01-335-9090 has freight characteristics.. 5120-01-335-9090 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
