5120-01-335-8141
Socket Wrench Socket
5120013358141 013358141 3122
An item having an internal drive at one end made to fit into the external drive end of a socket wrench handle, torque wrench, or power driven tool. The opposite end consists of various internal wrench shapes such as hexagon or square. It may include an integral universal joint. View more Socket Wrench Socket
September 2025
10
Marketplace 5120-01-335-8141
Request a Quotation from participating marketplace vendors
Related Documents 5120-01-335-8141 2+ Documents (More...)
RQST Updated Every Day 5120-01-335-8141 RQST NE Related Documents 5120-01-335-8141 2+ Documents ( More
EA NS Request Quotation Updated Every Day 5120-01-335-8141 RQST NE Updated Every Day 5120-01-335-8141
Restrictions 5120-01-335-8141
5120-01-335-8141 is a Socket Wrench Socket that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-335-8141
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-335-8141
- Spain (YB01)
- Effective Date:
- 1 Jun 2004
- Republic of Korea (ZH01)
- Effective Date:
- 1 Nov 1995
- Greece (ZU01)
- Effective Date:
- 1 Jun 2005
- Turkey (ZW01)
- Effective Date:
- 1 Dec 2005
Approved Sources 5120-01-335-8141
- Part Number
- Manufacturer
- Status
- 3122
- Manufacturer
- 79808 - Wright Tool Co (Active)
- Primary Buy
- Primary Buy
Datasheet 5120-01-335-8141
- Characteristic
- Specifications
- FIIG
- Specifications
- A102A0
- Drive End Shape [CTCT]
- Square Single End Internal
- Drive Surface Size [ATNC]
- 0.375 Inches Nominal Single End
- Features Provided [CBBL]
- Manual Tool
- Material [MATT]
- Steel Overall
- Overall Length [ABHP]
- 1.125 Inches Nominal
- Wrenching Surface Shape [CRWY]
- 12 Point Single End Internal
- Wrenching Surface Size [AJBR]
- 0.688 Nominal Inches Single End
- Style Designator [STYL]
- Internal-Internal
- Surface Treatment [SFTT]
- Chromium Overall
Similar Supply Items to 5120-01-335-8141
Freight Information 5120-01-335-8141
5120-01-335-8141 has freight characteristics.. 5120-01-335-8141 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
