5120-01-242-1514
Socket Wrench Set
5120012421514 012421514 J52140 52140 5200G
An assortment of various sizes of WRENCH, SOCKET and/or combinations of SOCKET, SOCKET WRENCH and HANDLE, SOCKET WRENCH. It may include related attachments such as ADAPTER, SOCKET WRENCH; EXTENSION, SOCKET WRENCH; BAR, SOCKET WRENCH HANDLE; RATCHET ATTACHMENT, SOCKET WRENCH; UNIVERSAL JOINT, SOCKET WRENCH and BIT, SCREWDRIVER. View more Socket Wrench Set
May 2023
13
Marketplace 5120-01-242-1514
Request a Quotation from participating marketplace vendors
Related Documents 5120-01-242-1514 5+ Documents (More...)
Photo 1/2 5120-01-242-1514 Photo 2/2 - - 1.
WRENCH SET,SOCKET RQST NS Request Quotation Updated Every Day J52140 RQST NE Updated Every Day
-10000-20LI HEMPALIN ENAMEL FARLIGE STOFFER 52140 52140-10000 Managed by Denmark NSN Created on 17 Oct
https//www.nsnlookup.com /fsg-80/fsc-8010/dk 8010-22-258-4845Hempalin Enamel8010222584845222584845 52140
-50630-20LI 52140 52140-50630 HEMPALIN ENAMEL FARLIGE STOFFER Managed by Denmark NSN Created on 17 Oct
https//www.nsnlookup.com /fsg-80/fsc-8010/dk 8010-22-258-4848Hempalin Enamel8010222584848222584848 52140
Restrictions 5120-01-242-1514
5120-01-242-1514 is a Socket Wrench Set that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-242-1514
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-242-1514
- NASA (G751)
- Effective Date:
- 1 Apr 1991
- US Navy (N9QG)
- Effective Date:
- 1 Apr 1991
- Supplementary Collaborators:
- GTHD
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Nov 2011
Approved Sources 5120-01-242-1514
- Part Number
- Manufacturer
- Status
- J52140
- Manufacturer
- 1CV05 - The Stanley Works (Active)
- Primary Buy
- Primary Buy
- 52140
- 1CV05 - The Stanley Works (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 5200G
- 93389 - Stanley-Proto Industrial Works Div (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-01-242-1514
- Characteristic
- Specifications
- FIIG
- Specifications
- A23800
- Component Quantity [AJJW]
- 58
- Nonsupply Items And Quantities [AJKD]
- Square Drive Size: 3/8 Inch: Material - Steel, Coating - Chrome; The Set Shall Consist Of One (1) Each Of The Following 58 Items (59 Including Tool Box); Sockets (12-Point), Long Length: Wrench Openings - 1/4, 5/16, 3/8, 7/16, 1/2, 9/16, 5/8, 11/16, 3/4, 13/16, 7/8, 15/16, 1 Inch; Regular Length: Wrench Openings - 1/4, 5/16, 3/8, 7/16, 1/2, 9/16, 5/8, 11/16, 3/4, 13/16, 7/8, 15/16, 1 Inch; Universal Sockets: Wrench Openings - 3/8, 7/16, 1/2, 9/16, 5/8, 11/16, 3/4; Sockets Single (Double 8-Point) Length: Standard Sizes - 1/4, 5/16, 3/8, 7/16, 1/2 Inch; Attachments: Universal Joint; Handles, Hinged: Length - 7-7/8 Inch; Speeder: Brace Type, Single Revolving Handgrip: Length - 17-1/2 Inches; Handles, T, Sliding Ratchet, Reversible: Length - 7 Inches; Adapter, Ratchet, Extension Bar, Solid: Length - 3, 6 And 12 Inches; Hex Bit Socket: Sizes - 1/4, 1/8, 3/16, 3/8, 5/16, 5/32, 7/32 Inch; Phillps Screwdriver Bit: Sizes - No. 2, 3, 4; Slotted Screwdriver Bit: Size - 1/4 Inch
- Furnished Items [AFJH]
- Steel Chest
DLA Procurement Analysis 5120-01-242-1514
Management Data 5120-01-242-1514
Navy
- Cognizance:
- 9Q
Similar Supply Items to 5120-01-242-1514
Freight Information 5120-01-242-1514
5120-01-242-1514 has freight characteristics managed by the Food and Drug Administration (FDA).It has a National Motor Freight Classification (NMFC) of 186620. A Sub NMFC of Z. It has a NMFC Description of TOOLS, NOI HAND OTHER THAN POWER. 5120-01-242-1514 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5120-01-242-1514 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5120-01-242-1514 is not classified as a special type of cargo when transported by water. 5120-01-242-1514 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
