5120-01-173-6253
Torque Wrench Adapter
5120011736253 011736253 MIL-W-8982 J-35205 M8982/3-184B 6046
An adapter which facilitates the use of a torque wrench in various applications. One end is designed for direct mating with the drive tang of a torque wrench and the other end designed to mate with the head of a bolt, nut, or the like, or made to fit into socket wrench or screwdriver bit. View more Torque Wrench Adapter
November 2025
18
Marketplace 5120-01-173-6253
Request a Quotation from participating marketplace vendors
Updated Every Day Updated Every Day
Updated Every Day Related Documents 5120-01-173-6253 5+ Documents (More...)
Photo 1/2 NSN 5120-01-173-6253 (Identification) 2/2 - - 1.
United States (US) 4. 5120-01-173-6253 Marketplace Restrictions Approved Sources Datasheet Management
M8982/3-184B SRES18 5120PL0844847 An adapter which facilitates the use of a torque wrench in various
Torque Wrench Adapter 5120011736253 011736253 a day Upgrade your Account Upgrade 5120-01-173-6253Torque
a day Upgrade your Account Upgrade 5120-01-066-3851Socket Wrench Socket5120010663851 010663851 MIL-W-8982
a day Upgrade your Account Upgrade 5120-01-367-3183Socket Wrench Socket5120013673183 013673183 MIL-W-8982
a day Upgrade your Account Upgrade 5120-01-173-6252Torque Wrench Adapter5120011736252 011736252 MIL-W-8982
your Account Upgrade 5120-01-064-1923Combination Box And Open End Wrench5120010641923 010641923 MIL-W-8982
Restrictions 5120-01-173-6253
5120-01-173-6253 is a Torque Wrench Adapter that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-173-6253
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-173-6253
- Spain (YB01)
- Effective Date:
- 1 Feb 1994
- Columbia (YC01)
- Effective Date:
- 1 Jun 2015
- Canada (ZC01)
- Effective Date:
- 1 Jun 2011
- Turkey (ZW01)
- Effective Date:
- 1 Dec 2005
Approved Sources 5120-01-173-6253
- Part Number
- Manufacturer
- Status
- 6046
- Manufacturer
- 688L6 - Wta Tool Llc (Active)
- Primary Buy
- Primary Buy
- MIL-W-8982
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- J-35205
- 33287 - Bosch Automotive Service Solutions (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- M8982/3-184B
- 81349 - Military Specifications (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 6046
- 63704 - Granco Industries Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-01-173-6253
- Characteristic
- Specifications
- FIIG
- Specifications
- A102A0
- Drive End Head Thickness [AJEU]
- 0.524 Inches Maximum
- Drive End Outside Diameter [AHMK]
- 1.055 Inches Maximum
- Drive End Shape [CTCT]
- Square Single End Internal
- Drive Surface Size [ATNC]
- 0.500 Inches Nominal Single End
- Material [MATT]
- Steel Overall
- Overall Length [ABHP]
- 3.000 Inches Nominal
- Special Features [FEAT]
- No. 18 Spline Size; Overall Length Is Center To Center Length
- Wrenching End Head Thickness [AJET]
- 0.406 Inches Nominal
- Wrenching End Outside Diameter [AHMJ]
- 0.825 Inches Maximum
- Wrenching Surface Flute Quantity [AJBU]
- 12
- Wrenching Surface Shape [CRWY]
- Spline Single End Internal
- Wrenching Surface Size [AJBR]
- 0.562 Inches Nominal Single End
- Style Designator [STYL]
- Box End
- Surface Treatment [SFTT]
- Chromium Overall
Similar Supply Items to 5120-01-173-6253
Freight Information 5120-01-173-6253
5120-01-173-6253 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186620. A Sub NMFC of Z. It has a NMFC Description of TOOLS, NOI HAND OTHER THAN POWER. 5120-01-173-6253 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5120-01-173-6253 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5120-01-173-6253 is not classified as a special type of cargo when transported by water. 5120-01-173-6253 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
