5120-01-142-9857
Torque Wrench
5120011429857 011429857 AS28431 TY2CL3 AS28431 64-031 B107.300 B107.14 GGG-W-686 TY3CL2 B107.14 TY2CLAST1DEC 501MMH 64-007 GGG-W-686
A manual tool for tightening various fasteners to a precise torque value. Consists of a handle and drive to accommodate female square drive sockets and other types of wrenching adapters. Torque value may be manually set and adjusted by user or may be provided as preset for production line use. A signaling device is generally provided to indicate when set torque value is reached. Handle is swung at right angle to axis of fastener rotation to apply torque. For items with handles that are spun in-line with axis of fastener rotation to apply torque, see SCREWDRIVER, TORQUE. View more Torque Wrench
November 2023
39
Marketplace 5120-01-142-9857
Request a Quotation from participating marketplace vendors
Related Documents 5120-01-142-9857 5+ Documents (More...)
CL2 B107.14M B107.14 TY2CLAST2DEB GGG-W -686 B107.300B107.14 TY2CLAST2DEA AS28431 TY1CL2 AS28431
6061AB B107.14 TY2CLAST1DEB B107.300 B107.300B107.14 TY2CLAST2DEA AS28431 - /us 5120-01-142-9857 Torque
CL2 CL2 B107.14M B107.14 CL2 B107.14M B107.14 6061AB B107.14 TY2CLAST1DEB B107.300 B107.300B107.14
TY2CLAST2DEA AS28431 -01 B107.14 QJR4600A B107.14 https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-
GGG-W-686 TY3CL2 B107.14 TY2CLAST2DEAAS28431 https//www.nsnlookup.com https//www.nsnlookup.com /fsg-
51/fsc-5120/us 5120-01-142-9857 Torque Wrench 5120011429857 011429857 TY2CL3 AS28431 64-031 B107.300B107.14
6061AB B107.300 LTC1 B107.14 https LTC1 B107.14 https TY2CLAST1DEB B107.300 https//www.nsnlookup.com
TY2CL2 B107.14 6061AB B107.300 LTC1 B107.14 https LTC1 LTC1 B107.14 https LTC1 B107.14 https TY2CLAST1DEB
TY1CL1 4LY41 6015B 1ARN4 AS28431 6015 B107.14 6015C B107.14 TY2CLAST1DEA B107.300 A manual tool for
B107.14 WRENCH,TORQUE 1 EA NS Request Quotation Subscribe to View Vendor Details... -6015 WRENCH,TORQUE
Restrictions 5120-01-142-9857
5120-01-142-9857 is a Torque Wrench that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-01-142-9857
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-142-9857
- US Army (A192)
- Effective Date:
- 1 Nov 2008
- Supplementary Receivers:
- CLCT
- NASA (G751)
- Effective Date:
- 1 Apr 1991
- US Marine Corps (MC14)
- Effective Date:
- 1 Jul 2014
- US Navy (N9QG)
- Effective Date:
- 1 Apr 1991
- Supplementary Collaborators:
- GTHSHD
- Supplementary Receivers:
- JV
- Brazil (YA01)
- Effective Date:
- 1 Oct 2000
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Australia (ZA01)
- Effective Date:
- 1 Feb 2004
- Canada (ZC01)
- Effective Date:
- 1 Apr 2016
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 2008
- United Kingdom (ZK01)
- Effective Date:
- 28 Oct 1991
- Netherlands (ZN01)
- Effective Date:
- 1 May 2013
- Portugal (ZP01)
- Effective Date:
- 1 Mar 2007
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Jun 2006
Approved Sources 5120-01-142-9857
- Part Number
- Manufacturer
- Status
- AS28431
- Manufacturer
- 0U583 - Sae International (Active)
- Incomplete Reference
- Incomplete Reference
- AS28431 TY2CL3
- 80244 - General Services Administration (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- AS28431
- 81343 - Society Of Automotive Engineers Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 64-031
- 03914 - Armstrong Bros Tool Co (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- B107.300
- 05047 - The American Society Of Mechanical (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- B107.14
- 05047 - The American Society Of Mechanical (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- GGG-W-686 TY3CL2
- 80244 - General Services Administration (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 64-031
- 08292 - Easco Hand Tools Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- B107.14 TY2CLAST1DEC
- 80244 - General Services Administration (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 501MMH
- 08194 - Consolidated Devices, Inc. (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 64-007
- 03914 - Armstrong Bros Tool Co (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- GGG-W-686
- 81348 - Federal Specifications Promulgated (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 64-031
- 636D0 - Apex Tool Group, Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 501MMH
- 3LSJ2 - Snap-On Incorporated (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-01-142-9857
- Characteristic
- Specifications
- FIIG
- Specifications
- A102A0
- Drive Surface Size [ATNC]
- 0.250 Inches Nominal Single End
- Drive End Shape [CTCT]
- Square Single End External
- Material [MATT]
- Steel Overall
- Nondefinitive Spec/Std Data [ZZZT]
- 2 Type And 3 Class
- Overall Length [ABHP]
- 7.900 Inches Nominal
- Special Features [FEAT]
- Plain Head
- Torque Scale Graduation [AJCH]
- 0.50 Inch-Pounds
- Torque Signal Method [AJDR]
- Feel Impulse
- Torque Capacity [AJCG]
- 5.0 Inch-Pounds Minimum And 50.0 Inch-Pounds Maximum
- Torque Indicating Mechanism [AJCF]
- Micrometer
- Specification/Standard Data [ZZZK]
- 81343-Sae As28431 Professional/Industrial Association Standard
- Style Designator [STYL]
- Micrometer End Drive
- Surface Treatment [SFTT]
- Chromium Overall
Management Data 5120-01-142-9857
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- CC
- Other Aircraft Categories
Multi-Application Aviation Spares
- Accounting Requirements:
- D
- Durable item.An item of Army property coded with an ARC of D in the AMDF. Durable items do not require property book accountability after issue from the stock record account but do require hand receipt control when issued to the user. Commercial and fabricated items similar to items coded D in the AMDF are considered durable items.
Navy
- Cognizance:
- 9Q
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 2
- Non-Critical Repair Part
- Echelon Management:
- 02
- Material Identification:
- O
- Ancillary Items/SL-3 Components
- Operational Test:
- 3
- Calibration Required
- Physical Category:
- 1
- Bin
Similar Supply Items to 5120-01-142-9857
Freight Information 5120-01-142-9857
5120-01-142-9857 has freight characteristics managed by the Food and Drug Administration (FDA).It has a National Motor Freight Classification (NMFC) of 186620. A Sub NMFC of Z. It has a NMFC Description of TOOLS, NOI HAND OTHER THAN POWER. 5120-01-142-9857 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5120-01-142-9857 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5120-01-142-9857 is not classified as a special type of cargo when transported by water. 5120-01-142-9857 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
