5120-01-030-1976
Face Spanner Wrench Socket
5120010301976 010301976 6872477
An item designed to be driven by an external or internal drive. It has a face type spanner end. View more Face Spanner Wrench Socket
May 2023
8
Marketplace 5120-01-030-1976
Request a Quotation from participating marketplace vendors
Related Documents 5120-01-030-1976 1+ Documents (More...)
Documents 5120-01-030-1976 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120
-01-030-1976 Face Spanner Wrench Socket 5120010301976 6872477 An item designed to be driven by an external
Restrictions 5120-01-030-1976
5120-01-030-1976 is a Face Spanner Wrench Socket that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5120-01-030-1976
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-01-030-1976
- US Army (A921)
- Effective Date:
- 1 Feb 2005
- Former MOE Rule:
- A182
- Supplementary Receivers:
- CT
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Republic of Korea (ZH01)
- Effective Date:
- 1 Mar 1998
- Turkey (ZW01)
- Effective Date:
- 1 Dec 2005
Approved Sources 5120-01-030-1976
- Part Number
- Manufacturer
- Status
- 6872477
- Manufacturer
- 73342 - Allison Transmission Inc (Active)
- Primary Buy
- Primary Buy
Datasheet 5120-01-030-1976
- Characteristic
- Specifications
- FIIG
- Specifications
- A102A0
- Drive End Shape [CTCT]
- Square Single End Internal
- Drive Surface Size [ATNC]
- 0.503 Inches Minimum Single End And 0.508 Inches Maximum Single End
- Angle Between Lugs [CTLN]
- 89.0 Degrees Minimum And 91.0 Degrees Maximum
- Opening Diameter [AGNJ]
- 1.660 Inches Minimum And 1.700 Inches Maximum
- Outside Diameter [ABKV]
- 1.660 Inches Minimum And 1.700 Inches Maximum
- Material [MATT]
- Steel Comp 4140 Overall
- Lug Length [AJAQ]
- 0.230 Inches Minimum And 0.250 Inches Maximum
- Lug Width [AHMM]
- 0.170 Inches Minimum And 0.175 Inches Maximum
- Material Document And Classification [MDCL]
- Fed Std 66 Fed Std Single Material Response Overall
- Overall Length [ABHP]
- 6.140 Inches Minimum And 6.180 Inches Maximum
- Style Designator [STYL]
- Lug
- Surface Treatment Document And Classification [STDC]
- Ams 2400 Assn Std Single Treatment Response Overall
- Surface Treatment [SFTT]
- Cadmium Overall
Weapon Systems (WSDC) 5120-01-030-1976
DLA Procurement Analysis 5120-01-030-1976
Management Data 5120-01-030-1976
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Mar 2021
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Oct 2020
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2019
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Army (DA)
- A
- V
- Discontinued Without Replacement
- V
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- BQ
- Rotary Wing Aircraft
T63-A-700 and T63-A-720
- Accounting Requirements:
- D
- Durable item.An item of Army property coded with an ARC of D in the AMDF. Durable items do not require property book accountability after issue from the stock record account but do require hand receipt control when issued to the user. Commercial and fabricated items similar to items coded D in the AMDF are considered durable items.
NATO Stock Numbers Related to 5120-01-030-1976
Freight Information 5120-01-030-1976
5120-01-030-1976 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186630. A Sub NMFC of X. It has a NMFC Description of TOOLS:NOI O/T PLSTC IN BBLS/BXS. 5120-01-030-1976 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5120-01-030-1976 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5120-01-030-1976 is not classified as a special type of cargo when transported by water. 5120-01-030-1976 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Procurement History 5120-01-030-1976 1 Records
Contracting Technical Data File (CTDF) 5120-01-030-1976 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- Y
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
