5120-00-809-3793
Spanner Wrench
5120008093793 008093793 809897 808875
A tool on which are located one or more pins, lugs, holes, keyways, or hooks, designed to engage matching holes, slots, or projections on a coupling, nut, or the like; for exerting a torsional force, concentrated at a point or points of a mating part, tending to turn the mating part about an axis. The drive end may have a hole for a separate straight bar used as a handle. Excludes WRENCH, BUNG. View more Spanner Wrench
January 2023
14
Marketplace 5120-00-809-3793
Request a Quotation from participating marketplace vendors
Related Documents 5120-00-809-3793 5+ Documents (More...)
/fsg-51/fsc-5120/us
8 EA NS Request Quotation Updated Every Day 5120-00-809-3793 RQST NE Updated Every Day 5120-00-809-3793
RQST Updated Every Day 5120-00-809-3793 RQST NE Related Documents 5120-00-809-3793 5+ Documents ( More
Documents 1430-99-631-0996 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-00-809-3793
Spanner Wrench 5120008093793 008093793 $1 a day Upgrade your Account Upgrade 5120-00-809-3793Spanner
Spanner Wrench 5120008093793 008093793 Upgrade for $1 a day Upgrade your Account Upgrade 5120-00
-809-3793Spanner Wrench5120008093793 008093793 809897 Vendor Details... 808875 WRENCH,SPANNER 21 EA NS
Upgrade your Account Upgrade 5365-00-083-7349Ring https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-00-809-3793
Spanner Wrench 5120008093793 008093793 5120-00-809-3793 5120008093793 008093793 is a tool on which
Spanner Wrench 5120008093793 008093793 Upgrade for $1 a day Upgrade your Account Upgrade 5120-00
-809-3793Spanner Wrench5120008093793 008093793 809897 Vendor Details... 808875 WRENCH,SPANNER 21 EA NS
Restrictions 5120-00-809-3793
5120-00-809-3793 is a Spanner Wrench that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-00-809-3793
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-00-809-3793
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5120-00-809-3793
- Part Number
- Manufacturer
- Status
- 809897
- Manufacturer
- 0AHP5 - Curtiss-Wright Controls, Inc. (Active)
- Primary Buy
- Primary Buy
- 808875
- 0AHP5 - Curtiss-Wright Controls, Inc. (Active)
- Secondary Buy
- Secondary Buy
Datasheet 5120-00-809-3793
- Characteristic
- Specifications
- FIIG
- Specifications
- A102A0
- Drive End Shape [CTCT]
- Square Single End Internal
- Drive Surface Size [ATNC]
- 0.504 Inches Minimum Single End And 0.513 Inches Maximum Single End
- Material [MATT]
- Steel Overall
- Opening Diameter [AGNJ]
- 3.500 Inches Nominal
- Lug Thickness [AHMN]
- 0.188 Inches Nominal
- Lug Width [AHMM]
- 0.250 Inches Nominal
- Material Document And Classification [MDCL]
- 66 Fed Std Single Material Response Overall
- Overall Length [ABHP]
- 11.875 Inches Nominal
- Style Designator [STYL]
- Lug
- Surface Treatment [SFTT]
- Chromium Overall And Zinc Overall
Similar Supply Items to 5120-00-809-3793
Freight Information 5120-00-809-3793
5120-00-809-3793 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186620. A Sub NMFC of Z. It has a NMFC Description of TOOLS, NOI HAND OTHER THAN POWER. 5120-00-809-3793 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5120-00-809-3793 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5120-00-809-3793 is not classified as a special type of cargo when transported by water. 5120-00-809-3793 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
