5120-00-601-9406
Open End Box Wrench
5120006019406 006019406 B107.100 B107.40 B107.40 TY1 1327 TG-05-1-00 TG1-05-1-00 28-140 6754 RXFS2022A RXH2022S
A nonadjustable wrench having an open end box wrenching feature on one or both ends for installing or removing packing nuts, flare nuts, conduit fittings, and the like. It may have a ratchet mechanism. Excludes WRENCH, BOX and WRENCH, OPEN END. View more Open End Box Wrench
May 2023
40
Marketplace 5120-00-601-9406
Request a Quotation from participating marketplace vendors
Updated Every Day Updated Every Day Updated Every Day
Updated Every Day Updated Every Day
Updated Every Day Related Documents 5120-00-601-9406 5+ Documents (More...)
TY1B107.40 RXH2426S B107.40 TY1 CAT 39 TY1 B107.100 TY1B107.40 RXH2426S B107.40 TY1 RXH2426S B107.40
TY1B107.40 RXH2426S B107.40 TY1 CAT 39 TY1 B107.100 TY1B107.40 RXH2426S B107.40 TY1 RXH2426S B107.40
TY1B107.40 RXH2426S B107.40 TY1 CAT 39 TY1 B107.100 CAT 39 TY1CL1 B107.9M TY4 B107.9M 9-4434 B107.40
RXH2426S B107.40 TY1 RXH2426S B107.40 TY1B107.100 B107.40 TY1 CAT 39 TY1 B107.100 CAT 39 TY1CL1 B107.9M
39 TY1 B107.100 TY1B107.40 RXH2426S B107.40 TY1 RXH2426S B107.40 TY1B107.40 RXH2426S B107.40 TY1 CAT
CAT 39 TY1 B107.100 TY1B107.40 RXH2426S B107.40 TY1 RXH2426S B107.40 TY1B107.40 RXH2426S B107.40 TY1
CAT 39 TY1 B107.100 https//www.nsnlookup.com /fsg-51/ 9-4434 B107.40 TY1 A group 9-4434 B107.40 TY1
39 TY1 B107.100 CAT TY1B107.40 RXH2426S B107.40 TY1 RXH2426S B107.40 of WRENCH B107.100 CAT 39 TY1 B107.100
of WRENCH B107.100 CAT 39 TY1 B107.100 CAT 39 TY1CL1 B107.9M TY4 B107.9M 9-4434 B107.40 9-4434 B107.40
TY1B107.40 RXH2426S B107.40 TY1 CAT 39 TY1 B107.100 CAT 39 TY1CL1 B107.9M TY4 B107.9M 9-4434 B107.40
Restrictions 5120-00-601-9406
5120-00-601-9406 is a Open End Box Wrench that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-00-601-9406
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-00-601-9406
- US Army (A192)
- Effective Date:
- 1 Apr 1991
- Supplementary Receivers:
- BF
- US Air Force (FGGS)
- Effective Date:
- 1 Apr 1991
- NASA (G751)
- Effective Date:
- 1 Apr 1991
- US Marine Corps (MC14)
- Effective Date:
- 1 Apr 1991
- US Navy (N9QG)
- Effective Date:
- 1 Apr 1991
- Supplementary Collaborators:
- GTHDHEJN
- Israel (YD01)
- Effective Date:
- 1 Aug 2016
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- United Kingdom (ZK01)
- Effective Date:
- 1 Nov 1995
Approved Sources 5120-00-601-9406
- Part Number
- Manufacturer
- Status
- B107.100
- Manufacturer
- 05047 - The American Society Of Mechanical (Active)
- Incomplete Reference
- Incomplete Reference
- B107.40
- 05047 - The American Society Of Mechanical (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- B107.40 TY1
- 80244 - General Services Administration (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 1327
- 36098 - Herbrand Tools Corp (Active)
- Secondary Buy
- Secondary Buy
- TG-05-1-00
- K7739 - Atmosphere Control International (Active)
- Secondary Buy
- Secondary Buy
- TG1-05-1-00
- K7739 - Atmosphere Control International (Active)
- Secondary Buy
- Secondary Buy
- 28-140
- 636D0 - Apex Tool Group, Llc (Active)
- Secondary Buy
- Secondary Buy
- 6754
- 688L6 - Wta Tool Llc (Active)
- Secondary Buy
- Secondary Buy
- RXFS2022A
- 55719 - Idsc Holdings Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- RXH2022S
- 55719 - Idsc Holdings Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 28-140
- 03914 - Armstrong Bros Tool Co (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 28-140
- 08292 - Easco Hand Tools Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 6754
- 63704 - Granco Industries Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-00-601-9406
- Characteristic
- Specifications
- FIIG
- Specifications
- A527Y0
- Material [MATT]
- Steel Overall
- Nondefinitive Spec/Std Data [ZZZT]
- 1 Type
- Large End Head Thickness [AJAU]
- 0.625 Inches Maximum
- Small End Head Thickness [AJAV]
- 0.625 Inches Maximum
- Overall Length [ABHP]
- 6.250 Inches Minimum
- Special Features [FEAT]
- Forged Steel
- Wrenching Surface Shape [CRWY]
- 6 Point Both Ends Internal
- Wrenching Surface Size [AJBR]
- 0.625 Inches Nominal First End
- Wrenching Surface Size [AJBR]
- 0.688 Inches Nominal Second End
- Specification/Standard Data [ZZZK]
- 05047-Asme B107.100 Professional/Industrial Association Standard
- Style Designator [STYL]
- Flare Nut Double End
- Surface Treatment [SFTT]
- Chromium Overall
NATO Stock Numbers Related to 5120-00-601-9406
Freight Information 5120-00-601-9406
5120-00-601-9406 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186620. A Sub NMFC of Z. It has a NMFC Description of TOOLS, NOI HAND OTHER THAN POWER. 5120-00-601-9406 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5120-00-601-9406 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5120-00-601-9406 is not classified as a special type of cargo when transported by water. 5120-00-601-9406 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
