5120-00-529-3074
Spanner Wrench
5120005293074 005293074 ME51528PC3 3250252PC3 51400
A tool on which are located one or more pins, lugs, holes, keyways, or hooks, designed to engage matching holes, slots, or projections on a coupling, nut, or the like; for exerting a torsional force, concentrated at a point or points of a mating part, tending to turn the mating part about an axis. The drive end may have a hole for a separate straight bar used as a handle. Excludes WRENCH, BUNG. View more Spanner Wrench
January 2023
2
Marketplace 5120-00-529-3074
Request a Quotation from participating marketplace vendors
Related Documents 5120-00-529-3074 5+ Documents (More...)
/fsg-51/fsc-5120/us
United States (US) 4. 5120-00-529-3074 Marketplace Restrictions Approved Sources Datasheet Management
WRENCH,SPANNER 32 EA NS Request Quotation 51400 WRENCH,SPANNER 32 EA NS Request Quotation Subscribe
www.nsnlookup.com /fsg-66/fsc-6625/us 6625-01-423-6025 Test Adapter Kit 6625014236025014236025 4000-51400
Spanner Wrench 5120005293074 005293074 WRENCH,SPANNER 32 EA NS Request Quotation Subscribe https
27020-51400 An externally threaded fastener the head of which is usually flat with a periphery not concentric
Spanner Wrench 5120005293074 005293074 Amplifier5996171251438 1712514389556 782 51400 https//www.nsnlookup.com
/fsg-93/fsc-9330/de
JavaScript in your web browser . 9330-12-382-0400Magnetized Plastic Strip9330123820400 1238204002476-51400
JavaScript in your web browser . 9330-12-382-0400Magnetized Plastic Strip9330123820400 1238204002476-51400
Control Amplifier 5996171251438 RQST NE Updated Every https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-00-529-3074
Spanner Wrench 5120005293074 005293074 Secondary Buy RNCC 5 RNVC 2 DAC 6 4610-51400 https https
Restrictions 5120-00-529-3074
5120-00-529-3074 is a Spanner Wrench that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-00-529-3074
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-00-529-3074
- NASA (G751)
- Effective Date:
- 1 Apr 1991
- US Navy (N9QG)
- Effective Date:
- 1 Apr 1991
- Supplementary Collaborators:
- JB
- Supplementary Receivers:
- HD
- United States of America (ZZ)
Approved Sources 5120-00-529-3074
- Part Number
- Manufacturer
- Status
- ME51528PC3
- Manufacturer
- 20038 - Stryten Energy Llc (Active)
- Primary Buy
- Primary Buy
- 3250252PC3
- 80064 - Naval Ship Systems Command (Active)
- Primary Buy
- Primary Buy
- 51400
- 20038 - Stryten Energy Llc (Active)
- Primary Buy
- Primary Buy
Datasheet 5120-00-529-3074
- Characteristic
- Specifications
- FIIG
- Specifications
- A102A0
- Angle Between Lugs [CTLN]
- 60.0 Degrees Nominal
- Material [MATT]
- Steel Overall
- Opening Diameter [AGNJ]
- 3.094 Inches Minimum And 3.156 Inches Maximum
- Lug Thickness [AHMN]
- 0.688 Inches Maximum
- Lug Width [AHMM]
- 0.500 Inches Nominal
- Overall Length [ABHP]
- 6.250 Inches Nominal
- Overall Width [ABMK]
- 3.469 Inches Minimum And 3.531 Inches Maximum
- Special Features [FEAT]
- Handle Wrapped In Black Plastic Electrical Tape
- Style Designator [STYL]
- Face Lug
- Surface Treatment [SFTT]
- Paint Overall
Management Data 5120-00-529-3074
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Feb 2020
- Department of the Navy (DN)
- EA
- Subscribe
- EA
Navy
- Cognizance:
- 9Q
Similar Supply Items to 5120-00-529-3074
Freight Information 5120-00-529-3074
5120-00-529-3074 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186620. A Sub NMFC of Z. It has a NMFC Description of TOOLS, NOI HAND OTHER THAN POWER. 5120-00-529-3074 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5120-00-529-3074 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5120-00-529-3074 is not classified as a special type of cargo when transported by water. 5120-00-529-3074 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
