5120-00-293-0137
Socket Wrench
5120002930137 002930137 GGG-W-641 GGG-W-641 TY1CL2 976A 36-3495
A wrench consisting of one or more sockets, integral with shank(s) or body. It may not be furnished with a handle when the handle is removable or when it is the "double end socket" and "single socket bar" types, each designed for use with the other or similar items. Excludes SOCKET, SOCKET WRENCH. View more Socket Wrench
May 2023
5
Marketplace 5120-00-293-0137
Request a Quotation from participating marketplace vendors
Related Documents 5120-00-293-0137 5+ Documents (More...)
GGG-W-641 WRENCH,SOCKET 24 EA NS Request Quotation Updated Every Day 5120-00-293-0137 RQST NE Updated
Socket Wrench 5120002930137002930137 002277389 GGG-W-641 TY1CL2 A wrench consisting of one or more
https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-00-227-7385 Socket Wrench 5120002277385 002277385 GGG-W-641
https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-00-293-0137 Socket Wrench 5120002930137 002930137
https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-00-227-7389 Socket Wrench 5120002277389 002277389 GGG-W-641
https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-00-239-9264 Socket Wrench 5120002399264 002399264 GGG-W-641
https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-00-720-0953 Socket Wrench 5120007200953 007200953 GGG-W-641
https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-01-053-5572 Socket Wrench 5120010535572 010535572 GGG-W-641
https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-00-239-9264 Socket Wrench 5120002399264 002399264 GGG-W-641
https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-00-227-7389 Socket Wrench 5120002277389 002277389 GGG-W-641
Restrictions 5120-00-293-0137
5120-00-293-0137 is a Socket Wrench that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-00-293-0137
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-00-293-0137
- Brazil (YA)
- Brazil (YA01)
- Effective Date:
- 1 Aug 2000
- Canada (ZC)
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5120-00-293-0137
- Part Number
- Manufacturer
- Status
- 976A
- Manufacturer
- 05506 - Martin Sprocket And Gear Inc (Active)
- Primary Buy
- Primary Buy
- GGG-W-641
- 81348 - Federal Specifications Promulgated (Active)
- Incomplete Standard
- Incomplete Standard
- GGG-W-641 TY1CL2
- 80244 - General Services Administration (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 36-3495
- 05506 - Martin Sprocket And Gear Inc (Active)
- Secondary Buy
- Secondary Buy
- 976A
- 65814 - Trw Inc Hand Tools Div Trw (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-00-293-0137
- Characteristic
- Specifications
- FIIG
- Specifications
- A527Y0
- Features Provided [CBBL]
- Removable Handle
- Material [MATT]
- Steel Overall
- Nondefinitive Spec/Std Data [ZZZT]
- 1 Type And 2 Class
- Overall Length [ABHP]
- 10.375 Inches Minimum
- Wrenching Surface Shape [CRWY]
- Hexagon Single End Internal
- Wrenching Surface Size [AJBR]
- 1.637 Inches Minimum Single End And 1.655 Inches Maximum Single End
- Style Designator [STYL]
- Single Socket T
- Surface Treatment [SFTT]
- Oxide Overall
NATO Stock Numbers Related to 5120-00-293-0137
Freight Information 5120-00-293-0137
5120-00-293-0137 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186620. A Sub NMFC of Z. It has a NMFC Description of TOOLS, NOI HAND OTHER THAN POWER. 5120-00-293-0137 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5120-00-293-0137 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5120-00-293-0137 is not classified as a special type of cargo when transported by water. 5120-00-293-0137 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
