5120-00-277-1577
Box Wrench
5120002771577 002771577 J2647SW 8816B 2647SW A-A-1360 GGG-W-636 TY12 GGG-W-636
A nonadjustable wrench having a box wrenching feature on one or both ends. Excludes WRENCH, OPEN END BOX; and WRENCH, BOX AND OPEN END, COMBINATION. View more Box Wrench
May 2023
10
Marketplace 5120-00-277-1577
Request a Quotation from participating marketplace vendors
Related Documents 5120-00-277-1577 5+ Documents (More...)
RQST NE Updated Every Day 2647SW RQST NE Updated Every Day 5120-00-277-1577 RQST NE Updated Every Day
RQST NE Updated Every Day 2647SW RQST NE Updated Every Day 5120-00-277-1577 RQST NE Updated Every Day
ADAPTER,CONNECTOR 2 https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-00-277-1577 Box Wrench 5120002771577
002771577,J2647SW for $1 a day Upgrade your Account Upgrade 5120-00-277-1577Box Wrench5120002771577
UNIT,ROTARY 2 EA NS Request Quotation 8816B VACUUM PUMP UNIT,ROTARY 2 EA NS Request Quotation FedMall
Box Wrench 5120002771577 002771577,J2647SW for $1 a day Upgrade your Account Upgrade 5120-00-277
2 EA NS Request Quotation 8816B ADAPTER,CONNECTOR 2 EA NS Request Quotation Updated Every Day 5935-01
https//www.nsnlookup.com /fsg-51/fsc-5120/us 5120-00-277-1577 Box Wrench 5120002771577 002771577,J2647SW
TY3 GGG-W-636 A nonadjustable B107.410 CAT 59 TY3 X940B 1989 J2635SW GGG-W-636 TY12 2635SW GGG-W-636
GGG-W-636 TY12 2635SW GGG-W-636 A nonadjustable wrench having a B107.410 B107.410 CAT 59 TY2 https//
Restrictions 5120-00-277-1577
5120-00-277-1577 is a Box Wrench that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-00-277-1577
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-00-277-1577
- NASA (G751)
- Effective Date:
- 1 Apr 1991
- US Navy (N9QG)
- Effective Date:
- 1 Jul 1996
- Former MOE Rule:
- NIQG
- Supplementary Collaborators:
- HD
- Brazil (YA01)
- Effective Date:
- 1 Aug 2000
Approved Sources 5120-00-277-1577
- Part Number
- Manufacturer
- Status
- J2647SW
- Manufacturer
- 1CV05 - The Stanley Works (Active)
- Primary Buy
- Primary Buy
- 8816B
- 8Z799 - Williams J H Industrial Products Inc (Active)
- Primary Buy
- Primary Buy
- 2647SW
- 1CV05 - The Stanley Works (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- A-A-1360
- 58536 - Federal Commercial Item Description (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- GGG-W-636 TY12
- 80244 - General Services Administration (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- GGG-W-636
- 81348 - Federal Specifications Promulgated (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-00-277-1577
- Characteristic
- Specifications
- FIIG
- Specifications
- A527Y0
- Hardness Rating [CQFM]
- 35.0 Rockwell C Minimum And 45.0 Rockwell C Maximum
- Head Thickness [AHML]
- 1.688 Inches Minimum
- Material [MATT]
- Steel Overall
- Nondefinitive Spec/Std Data [ZZZT]
- 12 Type
- Outside Diameter [ABKV]
- 4.156 Inches Minimum
- Overall Length [ABHP]
- 15.000 Inches Minimum
- Wrenching Surface Shape [CRWY]
- 12 Point Single End Internal
- Wrenching Surface Size [AJBR]
- 2.938 Inches Nominal Single End
- Special Markings [MARK]
- Wrench Size
- Style Designator [STYL]
- Striking
- Surface Treatment [SFTT]
- Oxide Overall Or Enamel Overall Or Phosphate Overall Or Zinc Overall
Management Data 5120-00-277-1577
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Feb 2020
- Department of the Navy (DN)
- EA
- Subscribe
- 1
- EA
Navy
- Cognizance:
- 9Q
NATO Stock Numbers Related to 5120-00-277-1577
Freight Information 5120-00-277-1577
5120-00-277-1577 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186620. A Sub NMFC of Z. It has a NMFC Description of TOOLS, NOI HAND OTHER THAN POWER. 5120-00-277-1577 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5120-00-277-1577 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5120-00-277-1577 is not classified as a special type of cargo when transported by water. 5120-00-277-1577 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
