5120-00-277-1250
Open End Wrench
5120002771250 002771250 A-A-1357 1008 6000036 GGG-W-636 TY5 GGG-W-636
A nonadjustable wrench having an open end wrenching feature on one or both ends. Excludes WRENCH, OPEN END BOX; WRENCH, LINEMAN'S; and WRENCH, BOX AND OPEN END, COMBINATION. View more Open End Wrench
May 2023
31
Marketplace 5120-00-277-1250
Request a Quotation from participating marketplace vendors
Related Documents 5120-00-277-1250 5+ Documents (More...)
to View Vendor Details... 1008 WRENCH,OPEN END 101 EA NS Request Quotation GGG-W-636 WRENCH,OPEN END
GGG-W-636 WRENCH,OPEN END 6 EA NS Request Quotation Updated Every 15 Minutes 5120-00-277-1250 BUY NE
TY5 GGG-W-636 A nonadjustable wrench having an open end wrenching feature on one or both ends GGG-W
1003 GGG-W-636 TY5 GGG-W-636 A nonadjustable wrench having an open end wrenching feature on one or both
GGG-W-636 WRENCH,OPEN END 5 EA NS Request Quotation Subscribe to View Vendor Details...
GGG-W-636 WRENCH,OPEN END 6 EA NS Request Quotation Updated Every 15 Minutes 5120-00-293-1346 BUY NE
WRENCH,OPEN END Request Quotation 1008 WRENCH,OPEN END 101 EA NS Request Quotation Subscribe to View
End Wrench 5120002771250 002771250 Upgrade your Account Upgrade 5120-00-277-1250Open End Wrench5120002771250
GGG-W-636 WRENCH,OPEN END 5 EA NS Request Quotation Subscribe to View Vendor Details...
Open End Wrench 5120002771250 002771250 1008 6000036 GGG-W-636 https//www.nsnlookup.com /fsg-51
Restrictions 5120-00-277-1250
5120-00-277-1250 is a Open End Wrench that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-00-277-1250
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-00-277-1250
- Brazil (YA01)
- Effective Date:
- 1 Aug 2000
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Thailand (YY01)
- Effective Date:
- 1 Feb 2015
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 5120-00-277-1250
- Part Number
- Manufacturer
- Status
- 6000036
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
- A-A-1357
- 58536 - Federal Commercial Item Description (Active)
- Incomplete Standard
- Incomplete Standard
- GGG-W-636 TY5
- 80244 - General Services Administration (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- GGG-W-636
- 81348 - Federal Specifications Promulgated (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 1008
- 65814 - Trw Inc Hand Tools Div Trw (Obsolete)
- Advisory Reference
- Advisory Reference
Datasheet 5120-00-277-1250
- Characteristic
- Specifications
- FIIG
- Specifications
- A527Y0
- Hardness Rating [CQFM]
- 40.0 Rockwell C Minimum And 55.0 Rockwell C Maximum
- Head Angle [CRCS]
- 15.0 Degrees Nominal
- Head Thickness [AHML]
- 0.750 Inches Maximum
- Material [MATT]
- Steel Overall
- Overall Length [ABHP]
- 12.000 Inches Minimum
- Special Features [FEAT]
- Forged Steel
- Torque Capacity [AJCG]
- 8500.0 Inch-Pounds Minimum
- Wrenching Surface Shape [CRWY]
- Oval Single End Internal
- Wrenching Surface Size [AJBR]
- 1.250 Inches Nominal Single End
- Style Designator [STYL]
- Single Head
- Surface Treatment [SFTT]
- Enamel Overall And Chromium Overall
NATO Stock Numbers Related to 5120-00-277-1250
Freight Information 5120-00-277-1250
5120-00-277-1250 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186620. A Sub NMFC of Z. It has a NMFC Description of TOOLS, NOI HAND OTHER THAN POWER. 5120-00-277-1250 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5120-00-277-1250 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5120-00-277-1250 is not classified as a special type of cargo when transported by water. 5120-00-277-1250 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
