5120-00-269-7971

Socket Wrench Attachment Universal Joint

5120002697971 002697971 AS4283 TY2CL1 S8 7379076-8 0738 7108 5166189 B107.10 B107.10M 12-947 B107.10 TY2CL1 B107.10M TY2CL1 U11 AS4283 A-A-2169 GGG-W-641 TY4CL2 S140 GGG-W-641 456720015904 10424475

A connection for socket wrenches and handles. Consists of an internal drive on one end and an external drive on the opposite end, of the same size, connected by a cross pin device to permit swivel up to 90 degrees (1.6 radians). View more Socket Wrench Attachment Universal Joint

Managed by United States

NSN Created on 1 Jan 1963

Data Last Changed
November 2023

NATO Update Count
80

NATO Data Quality

5120-00-269-7971 UNIVERSAL JOINT,SOCKET WRENCH ATTACHMENT 5120002697971 002697971 1/5 — 5120-00-269-7971 Photo 1/5

5120-00-269-7971 UNIVERSAL JOINT,SOCKET WRENCH ATTACHMENT 5120002697971 002697971 2/5 — 5120-00-269-7971 Photo 2/5

5120-00-269-7971 UNIVERSAL JOINT,SOCKET WRENCH ATTACHMENT 5120002697971 002697971 3/5 — 5120-00-269-7971 Photo 3/5

5120-00-269-7971 UNIVERSAL JOINT,SOCKET WRENCH ATTACHMENT 5120002697971 002697971 4/5 — 5120-00-269-7971 Photo 4/5

STYL Style 208 for 5120-00-269-7971 5/5 — NSN 5120-00-269-7971 (Identification) 5/5

Marketplace 5120-00-269-7971

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

S-140 UNIVERSAL JOINT,SOCKET WRENCH ATTACHMENT 2 EA NS

Subscribe to View Vendor Details...

S-8 UNIVERSAL JOINT,SOCKET WRENCH ATTACHMENT 2 EA NS

Subscribe to View Vendor Details...

S8 UNIVERSAL JOINT,SOCKET WRENCH ATTACHMENT 11 EA NS

Subscribe to View Vendor Details...

U11 UNIVERSAL JOINT,SOCKET WRENCH ATTACHMENT 1 EA NS

Subscribe to View Vendor Details...

GGG-W-641 UNIVERSAL JOINT,SOCKET WRENCH ATTACHMENT RQST NS

Subscribe to View Vendor Details...

12947 UNIVERSAL JOINT,SOCKET WRENCH ATTACHMENT 17 EA NS

AS4283 UNIVERSAL JOINT,SOCKET WRENCH ATTACHMENT 250 EA NS

S140 UNIVERSAL JOINT,SOCKET WRENCH ATTACHMENT 193 EA NS

Subscribe to View Vendor Details...

12947 UNIVERSAL JOINT,SOCKET WRENCH ATTACHMENT RQST NS

Subscribe to View Vendor Details...

U11 UNIVERSAL JOINT,SOCKET WRENCH ATTACHMENT 1 EA NS

Subscribe to View Vendor Details...

GGG-W-641 UNIVERSAL JOINT,SOCKET WRENCH ATTACHMENT 24 EA NS

Subscribe to View Vendor Details...

5120-00-269-7971 UNIVERSAL JOINT,SOCKET WRENCH ATTACHMENT RQST NS

Updated Every 15 Minutes

5120-00-269-7971 BUY NE

Updated Every Day

12-947 RQST NE

Updated Every Day

5120-00-269-7971 RQST NE

Updated Every Day

5120-00-269-7971 RQST

Updated Every Day

5120-00-269-7971 RQST NE

Restrictions 5120-00-269-7971

5120-00-269-7971 is a Socket Wrench Attachment Universal Joint that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.

Import and Export 5120-00-269-7971

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 5120-00-269-7971

US Army (A192)
Effective Date:: 1 Apr 1991
Supplementary Receivers:: AMCTCLBFBDAZ; AMC 0 AMSC 0 IMC Z IMCACTY CD

US Coast Guard (C014)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0

US Air Force (FGGS)
Effective Date:: 1 Apr 1991
Supplementary Receivers:: TT; AMC 0 AMSC 0 IMC Z IMCACTY TG

NASA (G751)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0

NASA (G752)
Effective Date:: 1 Jul 2011; AMC 0 AMSC 0 AAC L

NASA (G861)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0

NASA (G881)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0

NASA (G901)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0

US Marine Corps (MC14)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0 IMC Z IMCACTY PA

US Navy (N9QG)
Effective Date:: 1 Jun 2008
Supplementary Collaborators:: GT; AMC 0 AMSC 0 IMC Z IMCACTY GH

Austria (WB01)
Effective Date:: 1 Feb 2005

Hungary (WH01)
Effective Date:: 1 Oct 2011

Lithuania (WI01)
Effective Date:: 1 Jun 2002

Poland (WP01)
Effective Date:: 1 Feb 2005

Brazil (YA01)
Effective Date:: 1 Aug 2000

Spain (YB01)
Effective Date:: 1 Apr 1991

Israel (YD01)
Effective Date:: 1 Aug 2016

Singapore (YJ01)
Effective Date:: 1 Apr 1991

Malaysia (YW01)
Effective Date:: 1 Apr 1991

Thailand (YY01)
Effective Date:: 1 Feb 2015

Australia (ZA01)
Effective Date:: 1 Apr 1991

Belgium (ZB01)
Effective Date:: 1 Dec 1999

Canada (ZC01)
Effective Date:: 1 Apr 1991

New Zealand (ZE01)
Effective Date:: 1 Apr 1991

France (ZF01)
Effective Date:: 1 May 2015

Germany (ZG01)
Effective Date:: 1 Apr 1991

Republic of Korea (ZH01)
Effective Date:: 1 Apr 1991

United Kingdom (ZK01)
Effective Date:: 1 Apr 1991

Portugal (ZP01)
Effective Date:: 1 Apr 1991

Italy (ZR01)
Effective Date:: 1 Jul 1997

Denmark (ZS01)
Effective Date:: 1 Apr 1991

Greece (ZU01)
Effective Date:: 1 Apr 1991

Turkey (ZW01)
Effective Date:: 1 Nov 1998

NATO Maintenance and Supply Agency (ZX01)
Effective Date:: 1 Sep 2004

Approved Sources 5120-00-269-7971

Part Number
Manufacturer
Status
AS4283: 0U583 - Sae International (Active); Incomplete Reference; RNCC 3 RNVC 1 DAC 4
AS4283 TY2CL1: 80244 - General Services Administration (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 4
S8: C7127 - Sna Germany Gmbh (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 3
7379076-8: 53711 - Naval Sea Systems Command (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 4
0738 7108: ZD484 - J. Blackwood & Son Pty Ltd (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 3
5166189: 53711 - Naval Sea Systems Command (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 4
B107.10: 05047 - The American Society Of Mechanical (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
B107.10M: 05047 - The American Society Of Mechanical (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
12-947: 636D0 - Apex Tool Group, Llc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
B107.10 TY2CL1: 80244 - General Services Administration (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
12-947: 03914 - Armstrong Bros Tool Co (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
B107.10M TY2CL1: 80244 - General Services Administration (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
U11: 79808 - Wright Tool Co (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
12-947: 08292 - Easco Hand Tools Inc (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
AS4283: 81343 - Society Of Automotive Engineers Inc (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
A-A-2169: 58536 - Federal Commercial Item Description (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 3
GGG-W-641 TY4CL2: 80244 - General Services Administration (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 3
S140: 18702 - Ducommun Metals Co (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC X
GGG-W-641: 81348 - Federal Specifications Promulgated (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 3
456720015904: 0000V - Ncb Hungary (Honvedsegi Egyseges (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
10424475: A486G - Nimikkeistokeskus Ncb Finland (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9

Datasheet 5120-00-269-7971

Characteristic
Specifications
FIIG: A102A0
Drive End Shape [CTCT]: Square Second End Internal
Drive End Shape [CTCT]: Square First End External
Drive Surface Size [ATNC]: 0.500 Inches Nominal Both Ends
Environmental Attribute Code [ENAC]: Plastics Removal In The Marine Environment (Prime) Product
Features Provided [CBBL]: Manual Tool
Hardness Rating [CQFM]: 38.0 Rockwell C Minimum And 54.0 Rockwell C Maximum
Material [MATT]: Steel Overall
Nondefinitive Spec/Std Data [ZZZT]: 2 Type And 1 Class
Outside Diameter [ABKV]: 1.010 Inches Maximum
Overall Length [ABHP]: 2.781 Inches Maximum
Specification/Standard Data [ZZZK]: 81343-Sae As4283 Professional/Industrial Association Standard
Style Designator [STYL]: External-Internal
Surface Treatment [SFTT]: Chromium Overall

Subscribe
View Data

DLA Procurement Analysis 5120-00-269-7971

DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 5120-00-269-7971

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Jan 2023: General Services Administration (TG); EA; Subscribe; 6
Mar 2022: Department of the Army (DA); EA; Subscribe; 6
Oct 2014: Department of the Air Force (DF); EA; Subscribe; 6

MOE: USC; Code; Statement; Order of Use; Jump To Code; Qty Per Assy; UOM; Technical Document; Quantative Expression
US Marine Corps (DM): M; 0; Reversal Of Phrase Code Z 5120-01-430-7768
US Marine Corps (DM): M; 4; Reversal Of Phrase Code A 5120-00-289-8430

Army

Materiel Category and Inventory Manager:

E: General Supplies (DLA/GSA Items)

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

2: Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.

Weapons System / End Item / Homogeneous Group:

00: DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Air Force

Fund:

SF: Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point

Budget:

9: 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors

Price Validation Code:

N: The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.

Expendability Recoverability Repairability:

N: Expendable. Condemn at User. Stock Fund (except Munitions).

Navy

Cognizance:

9Q

Marine Corps

Stores Account:

1: Stock Fund Account Item

Combat Essentiality:

2: Non-Critical Repair Part

Echelon Management:

02

Operational Test:

: No Special Procedures

Similar Supply Items to 5120-00-269-7971

Freight Information 5120-00-269-7971

5120-00-269-7971 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186620. A Sub NMFC of Z. It has a NMFC Description of TOOLS, NOI HAND OTHER THAN POWER. 5120-00-269-7971 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5120-00-269-7971 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5120-00-269-7971 is not classified as a special type of cargo when transported by water. 5120-00-269-7971 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
