5120-00-199-6996
Socket Wrench Socket
5120001996996 001996996 B107.1 B107.1 TY1CL2 B107.1 CL1STB 1627HP SP18MS
An item having an internal drive at one end made to fit into the external drive end of a socket wrench handle, torque wrench, or power driven tool. The opposite end consists of various internal wrench shapes such as hexagon or square. It may include an integral universal joint. View more Socket Wrench Socket
May 2023
27
Marketplace 5120-00-199-6996
Request a Quotation from participating marketplace vendors
Related Documents 5120-00-199-6996 5+ Documents (More...)
TY1CL2 12-344 B107.1 CL1STB https//www.nsnlookup.com Socket Wrench Socket 5120012994672 012994672 B107.1
-01-151-4249 Socket Wrench Socket 5120011514249 011514249 B107.1 TY1CL2 J-22799 B107.1 CL1STB An item
into the external TY1CL2 IPL16C FRS IPL16C An item TY1CL2 900AS/L-9/16 67684 009000319 GGG-W-641 B107.1
Socket Wrench Socket 5120001996996 001996996 B107.1 TY1CL2B107.1 CL1STB 1627HP SP18MS An item having
5120012994672 012994672 B107.1 TY1CL2 12-344 B107.1 CL1STB https//www.nsnlookup.com /fsg-51/fsc-5120
TY1CL2 1309607-101 B107.1 CL1STB An item having an internal drive at one end made to fit into B107.1
CL1STB B107.1 TY1CL2 B107.1 An item having an internal drive at one end made to fit into the external
TY1CL2GGG-W-641A-A-1408 7ML GGG-W-641 TY2CL1STB B107.1 CL1STB An item having an internal drive TY1CL2
CL1STB -641 an internal drive B107.1 TY1CL2 IN2816TD GGG-W-641 TY2CL2STB 7ML GGG-W- TY2CL1STB B107.1
IN2816TD GGG-W -641 TY2CL2STB drive B107.1 B107.1 CL1STB An item having an internal drive B107.1 TY1CL2
Restrictions 5120-00-199-6996
5120-00-199-6996 is a Socket Wrench Socket that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-00-199-6996
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-00-199-6996
- US Army (A192)
- Effective Date:
- 1 Apr 1991
- Supplementary Receivers:
- BDBF
- US Coast Guard (C014)
- Effective Date:
- 1 Apr 1991
- US Air Force (FGGS)
- Effective Date:
- 1 Apr 1991
- NASA (G751)
- Effective Date:
- 1 Apr 1991
- US Navy (N9QG)
- Effective Date:
- 1 Apr 1991
- Supplementary Collaborators:
- GTKEJNHD
- Spain (YB01)
- Effective Date:
- 1 Aug 2015
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Nov 2003
Approved Sources 5120-00-199-6996
- Part Number
- Manufacturer
- Status
- B107.1
- Manufacturer
- 05047 - The American Society Of Mechanical (Active)
- Incomplete Reference
- Incomplete Reference
- B107.1 TY1CL2
- 80244 - General Services Administration (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- B107.1 CL1STB
- 80244 - General Services Administration (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 1627HP
- 60043 - American Kal Enterprises, Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- SP18MS
- 11728 - Hercules Tool Corp (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-00-199-6996
- Characteristic
- Specifications
- FIIG
- Specifications
- A102A0
- Drive End Outside Diameter [AHMK]
- 1.080 Inches Maximum
- Drive End Shape [CTCT]
- Square Single End Internal
- Drive Surface Size [ATNC]
- 0.500 Inches Nominal Single End
- Features Provided [CBBL]
- Manual Tool
- Material [MATT]
- Steel Overall
- Nondefinitive Spec/Std Data [ZZZT]
- 1 Type And 2 Class
- Overall Length [ABHP]
- 3.562 Inches Minimum
- Special Features [FEAT]
- Spark Plug Type; Non-Aircraft; For 18Mm Spark Plugs; 13/16 In. Male Hex At Drive End
- Wrenching End Opening Depth [AJAP]
- 0.218 Nominal Mils
- Wrenching End Outside Diameter [AHMJ]
- 1.188 Inches Maximum
- Wrenching Surface Shape [CRWY]
- 6 Point Single End Internal
- Wrenching Surface Size [AJBR]
- 0.875 Inches Nominal Single End
- Specification/Standard Data [ZZZK]
- 05047-Asme B107.1 Professional/Industrial Association Standard
- Style Designator [STYL]
- Internal-Internal
- Surface Treatment [SFTT]
- Chromium Overall
Management Data 5120-00-199-6996
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9Q
Similar Supply Items to 5120-00-199-6996
Freight Information 5120-00-199-6996
5120-00-199-6996 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186620. A Sub NMFC of Z. It has a NMFC Description of TOOLS, NOI HAND OTHER THAN POWER. 5120-00-199-6996 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5120-00-199-6996 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5120-00-199-6996 is not classified as a special type of cargo when transported by water. 5120-00-199-6996 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
