5120-00-184-8654
Open End Wrench
5120001848654 001848654 B107.100 B107.100 CAT 39 TY2CL3 3719 DA30 A-A-1359 GGG-W-636 TY16ST1 GGG-W-636
A nonadjustable wrench having an open end wrenching feature on one or both ends. Excludes WRENCH, OPEN END BOX; WRENCH, LINEMAN'S; and WRENCH, BOX AND OPEN END, COMBINATION. View more Open End Wrench
May 2023
31
Marketplace 5120-00-184-8654
Request a Quotation from participating marketplace vendors
Related Documents 5120-00-184-8654 5+ Documents (More...)
GGG-W-636 TY6 B107.6 B107.39 B107.100 CAT 39 TY2CL3 fsc https//www.nsnlookup.com /fsg-51/fsc-5120/us
B107.39 179-012 GGG-W-636 TY6 B107.100 CAT 39 TY2CL3 B107.39 GGG-W-636 WRENCH,OPEN END 6 EA NS Request
/fsg-51/fsc-5120/us 5120-00-595-9017 Open End Wrench 5120005959017 005959017 B107.100 CAT 39 TY2CL3
/fsg-51/fsc-5120/us 5120-00-184-8654 Open End Wrench 5120001848654 001848654 B107.100 CAT 39 TY2CL3
-51/fsc-5120/us 5120-00-184-8654 Open End Wrench 5120001848654 001848654 B107.100 CAT 39 TY2CL3 3719
179-012 GGG-W-636 TY6 B107.100 CAT 39 TY2CL3 B107.39 fsc-5120/us 5120- 00-184-8652 Open End Wrench 5120001848652
GGG-W-636 WRENCH,OPEN END 6 EA NS Request Quotation B107.100 WRENCH,OPEN END 6 EA NS Request Quotation
TY16ST1 DA46 A nonadjustable wrench having an open end wrenching feature on one or both B107.100
Open End Wrench 5120001848654 001848654 B107.100 CAT 39 TY2CL3 3719 DA30 A-A-1359GGG-W-636 TY16ST1GGG-W
-636 A nonadjustable wrench having V7 ES-306 A-A-1355 E26 B107.39 179-012 GGG-W-636 TY6 B107.100 CAT
Restrictions 5120-00-184-8654
5120-00-184-8654 is a Open End Wrench that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-00-184-8654
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-00-184-8654
- US Army (A192)
- Effective Date:
- 1 Apr 1991
- Supplementary Receivers:
- BF
- US Air Force (FGGS)
- Effective Date:
- 1 Apr 1991
- Supplementary Receivers:
- TT
- NASA (G751)
- Effective Date:
- 1 Apr 1991
- US Marine Corps (MC14)
- Effective Date:
- 1 Dec 2015
- US Navy (N9QG)
- Effective Date:
- 1 Apr 1991
- Supplementary Collaborators:
- GTHD
- Brazil (YA01)
- Effective Date:
- 1 Aug 2000
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Mar 2005
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Sep 2004
Approved Sources 5120-00-184-8654
- Part Number
- Manufacturer
- Status
- B107.100
- Manufacturer
- 05047 - The American Society Of Mechanical (Active)
- Incomplete Reference
- Incomplete Reference
- 3719
- 05506 - Martin Sprocket And Gear Inc (Active)
- Primary Buy
- Primary Buy
- DA30
- 76377 - Stanley Industrial & Automotive Llc (Active)
- Primary Buy
- Primary Buy
- B107.100 CAT 39 TY2CL3
- 80244 - General Services Administration (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- A-A-1359
- 58536 - Federal Commercial Item Description (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- GGG-W-636 TY16ST1
- 80244 - General Services Administration (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- GGG-W-636
- 81348 - Federal Specifications Promulgated (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-00-184-8654
- Characteristic
- Specifications
- FIIG
- Specifications
- A527Y0
- Material [MATT]
- Steel Overall
- Surface Treatment [SFTT]
- Chromium Overall
- Style Designator [STYL]
- Double Head
- Overall Length [ABHP]
- 8.625 Inches Minimum
- Large End Head Thickness [AJAU]
- 0.297 Inches Maximum
- Small End Head Thickness [AJAV]
- 0.297 Inches Maximum
- Small End Head Angle [CTHK]
- 15.0 Degrees Nominal
- Large End Head Angle [CWGT]
- 60.0 Degrees Nominal
- Wrenching Surface Size [AJBR]
- 0.938 Inches Nominal Both Ends
- Wrenching Surface Shape [CRWY]
- Oval Both Ends Internal
- Special Features [FEAT]
- Forged Steel
Management Data 5120-00-184-8654
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Feb 2020
- Department of the Air Force (DF)
- EA
- Subscribe
- 6
- EA
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9Q
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 2
- Non-Critical Repair Part
- Echelon Management:
- 02
- Operational Test:
- 0
- Physical Category:
- 1
- Bin
NATO Stock Numbers Related to 5120-00-184-8654
Freight Information 5120-00-184-8654
5120-00-184-8654 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186620. A Sub NMFC of Z. It has a NMFC Description of TOOLS, NOI HAND OTHER THAN POWER. 5120-00-184-8654 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5120-00-184-8654 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5120-00-184-8654 is not classified as a special type of cargo when transported by water. 5120-00-184-8654 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
