5120-00-177-7324
Socket Wrench Screwdriver Attachment
5120001777324 001777324 80159 10-712 10-615
An attachment designed to fit over the square external drive end of a HANDLE, SOCKET WRENCH; WRENCH, TORQUE; and the like consisting of one or two-piece configuration having a screw driving tip on one end. Excludes BIT, SCREWDRIVER. View more Socket Wrench Screwdriver Attachment
August 2023
49
Marketplace 5120-00-177-7324
Request a Quotation from participating marketplace vendors
Updated Every Day Updated Every Day Updated Every Day
Updated Every Day Updated Every Day
Updated Every Day Related Documents 5120-00-177-7324 5+ Documents (More...)
Photo 1/4 5120-00-177-7324 Photo 2/4 5120-00-177-7324 Photo 3/4 NSN 5120-00-177-7324 (Identification
Updated Every Day 10-712 RQST NE Updated Every Day 10-615 RQST NE Updated Every Day 5120-00-177-7324
/fsg-63/fsc-6320/uk
14-285-4411 Tube Elbow 4730142854411 142854411,80159 9225Locking Pin And Spr3825218939225 218939225 80159
to enable JavaScript in your web browser . 6320-99-319 -0685Frame Assembly6320993190685 993190685 80159
enable JavaScript in your web browser . 6605-99-172 -9800Speed Front Frame6605991729800 991729800 80159
enable JavaScript in your web browser . 6605-99-172 -9800Speed Front Frame6605991729800 991729800 80159
enable JavaScript in your web browser . 5820-99-521-2326Radio Fre Parts Kit5820995212326 995212326 80159
Tube Elbow 4730142854411 142854411,80159 80159 https//www.nsnlookup.com /fsg-63/fsc-6320/uk 6320 https
99-521-2326 5+ Documents ( More... ) https//www.nsnlookup.com /fsg-58/fsc-5820/uk 5820-99-521-2326 80159
enable JavaScript in your web browser . 3825-21-893-9225Locking Pin And Spr3825218939225 218939225 80159
Restrictions 5120-00-177-7324
5120-00-177-7324 is a Socket Wrench Screwdriver Attachment that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-00-177-7324
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-00-177-7324
- US Army (A192)
- Effective Date:
- 1 Apr 1991
- Supplementary Receivers:
- BDBF
- US Air Force (FGGS)
- Effective Date:
- 1 Apr 1991
- NASA (G751)
- Effective Date:
- 1 Apr 1991
- US Marine Corps (MC14)
- Effective Date:
- 1 Apr 1991
- US Navy (N9QG)
- Effective Date:
- 1 Apr 1991
- Supplementary Collaborators:
- GTJNHD
- Poland (WP01)
- Effective Date:
- 1 Nov 2004
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Kuwait (YK01)
- Effective Date:
- 1 Jan 2015
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- United Kingdom (ZK01)
- Effective Date:
- 1 Nov 1994
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Feb 2016
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 5120-00-177-7324
- Part Number
- Manufacturer
- Status
- 80159
- Manufacturer
- 636D0 - Apex Tool Group, Llc (Active)
- Primary Buy
- Primary Buy
- 10-712
- 636D0 - Apex Tool Group, Llc (Active)
- Original Design
- Original Design
- 10-712
- 08292 - Easco Hand Tools Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 10-615
- 03914 - Armstrong Bros Tool Co (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 10-712
- 03914 - Armstrong Bros Tool Co (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-00-177-7324
- Characteristic
- Specifications
- FIIG
- Specifications
- A102A0
- Drive Surface Size [ATNC]
- 0.250 Inches Nominal Single End
- Blade Length [AEAE]
- 1.000 Inches Nominal
- Features Provided [CBBL]
- Manual Tool And Replaceable Bit
- Material [MATT]
- Steel Overall
- Outside Diameter [ABKV]
- 0.500 Inches Nominal
- Overall Length [ABHP]
- 1.875 Inches Nominal
- Wrenching Surface Shape [CRWY]
- Hexagon Single End External
- Wrenching Surface Size [AJBR]
- 0.219 Inches Nominal Single End
- Style Designator [STYL]
- Hexagon
- Surface Treatment [SFTT]
- Oxide Bit
- Surface Treatment [SFTT]
- Chromium Drive Surface
Management Data 5120-00-177-7324
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9Q
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- 02
- Operational Test:
- No Special Procedures
Similar Supply Items to 5120-00-177-7324
Freight Information 5120-00-177-7324
5120-00-177-7324 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186620. A Sub NMFC of Z. It has a NMFC Description of TOOLS, NOI HAND OTHER THAN POWER. 5120-00-177-7324 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5120-00-177-7324 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5120-00-177-7324 is not classified as a special type of cargo when transported by water. 5120-00-177-7324 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
