5120-00-063-7992
Box Wrench
5120000637992 000637992 TX13305
A nonadjustable wrench having a box wrenching feature on one or both ends. Excludes WRENCH, OPEN END BOX; and WRENCH, BOX AND OPEN END, COMBINATION. View more Box Wrench
January 2023
7
Marketplace 5120-00-063-7992
Request a Quotation from participating marketplace vendors
Related Documents 5120-00-063-7992 1+ Documents (More...)
,TX13305 TX13305 A nonadjustable wrench having a box wrenching feature on one or both ends.
WRENCH,BOX RQST NS Request Quotation Updated Every Day 5120-00-063-7992 RQST NE Updated Every Day 5120
Restrictions 5120-00-063-7992
5120-00-063-7992 is a Box Wrench that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5120-00-063-7992
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5120-00-063-7992
- NASA (G751)
- Effective Date:
- 1 Apr 1991
- US Navy (N9QG)
- Effective Date:
- 1 Apr 1991
- Supplementary Collaborators:
- KE
- Turkey (ZW01)
- Effective Date:
- 1 Sep 2009
Approved Sources 5120-00-063-7992
- Part Number
- Manufacturer
- Status
- TX13305
- Manufacturer
- 94697 - Moog Inc (Active)
- Primary Buy
- Primary Buy
- TX13305
- 19156 - Moog Inc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- TX13305
- 79294 - E-Systems Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5120-00-063-7992
- Characteristic
- Specifications
- FIIG
- Specifications
- A527Y0
- Head Thickness [AHML]
- 0.200 Inches Minimum And 0.250 Inches Maximum
- Material [MATT]
- Steel Comp 4130 Overall
- Special Features [FEAT]
- 0.375 Dia Through Hole Located On Centerline 0.880 In. From End Of Handle
- Overall Length [ABHP]
- 15.760 Inches Minimum And 15.880 Inches Maximum
- Overall Width [ABMK]
- 5.760 Inches Minimum And 6.000 Inches Maximum
- Wrenching Surface Shape [CRWY]
- Hexagon Single End Internal
- Wrenching Surface Size [AJBR]
- 4.000 Inches Nominal Single End
- Style Designator [STYL]
- Straight Single Head
Management Data 5120-00-063-7992
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2012
- Department of the Navy (DN)
- EA
- Subscribe
- 1
- EA
Navy
- Cognizance:
- 9Q
Similar Supply Items to 5120-00-063-7992
Freight Information 5120-00-063-7992
5120-00-063-7992 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186620. A Sub NMFC of Z. It has a NMFC Description of TOOLS, NOI HAND OTHER THAN POWER. 5120-00-063-7992 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5120-00-063-7992 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5120-00-063-7992 is not classified as a special type of cargo when transported by water. 5120-00-063-7992 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
