5110-01-434-9880
Hand Cold Chisel
5110014349880 014349880 70-307
A metal cutting hand tool less than 18 inches (457.2 mm) in length, having a straight, double beveled symmetrical cutting edge on one end, with cutting edge equal or greater than the distance between flats of stock. The opposite end contains a striking head. View more Hand Cold Chisel
May 2023
11
Marketplace 5110-01-434-9880
Request a Quotation from participating marketplace vendors
Related Documents 5110-01-434-9880 4+ Documents (More...)
NE Updated Every Day 5110-01-434-9880 RQST Updated Every Day 5110-01-434-9880 RQST NE Related Documents
Updated Every Day 5110-01-434-9880 RQST NE Updated Every Day 5110-01-434-9880 RQST Updated Every Day
Restrictions 5110-01-434-9880
5110-01-434-9880 is a Hand Cold Chisel that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5110-01-434-9880
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5110-01-434-9880
- Denmark (ZS01)
- Effective Date:
- 1 Jul 2005
Approved Sources 5110-01-434-9880
- Part Number
- Manufacturer
- Status
- 70-307
- Manufacturer
- 636D0 - Apex Tool Group, Llc (Active)
- Primary Buy
- Primary Buy
- 70-307
- 03914 - Armstrong Bros Tool Co (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 70-307
- 08292 - Easco Hand Tools Inc (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5110-01-434-9880
- Characteristic
- Specifications
- FIIG
- Specifications
- A533X0
- Material [MATT]
- Steel
- Cutting Edge Width [BGLQ]
- 0.438 Inches Nominal
- Overall Length [ABHP]
- 6.000 Inches Nominal
- Shank Shape [ASWL]
- Hexagonal
- Shank Width Across Flats [BWLP]
- 0.375 Inches Nominal
Management Data 5110-01-434-9880
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Jan 2008
- Department of the Air Force (DF)
- EA
- Subscribe
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Air Force (DF)
- F
- N
- Disposal
- N
Similar Supply Items to 5110-01-434-9880
Freight Information 5110-01-434-9880
5110-01-434-9880 has freight characteristics.. 5110-01-434-9880 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
