5110-00-585-8431
Woodworking Butt Chisel
5110005858431 005858431 B107.410 1048 B107.410 CAT 44 TY2 GNK 1048 108BC 16-910 GGG-C-311 TY1CL3 GGG-C-311 B107.44 B107.44 TY2
A wood cutting hand tool consisting of a straight steel blade from 2-1/2 inches (63.5 mm) to 3-1/2 inches (88.9 mm) long, having a square cutting edge. A nonmetallic handle is fixed to a tang or socket and may contain a striking cushion. View more Woodworking Butt Chisel
November 2023
22
Marketplace 5110-00-585-8431
Request a Quotation from participating marketplace vendors
Related Documents 5110-00-585-8431 5+ Documents (More...)
TY2 GGG-C-311 32-6 B107.44 TY2 A wood cutting https//www.nsnlookup.com /fsg-51/fsc-5110/us 5110-00-186
-8169 Paring Chisel 5110001868169 001868169 B107.410 CAT 44 TY2 32-5 828-C3205 046302 B107.44 TY2GGG-C
/fsc-5110/us 5110-00-585-8431 Woodworking Butt Chisel 5110005858431 1048 B107.410 CAT 44 TY2 GNK 1048
108BC 16-910 GGG-C-311 TY1CL3 GGG-C-311 B107.44 B107.44 TY2 A wood A wood cutting hand TY2CL5 https/
TY2 046303 828-C3206 GGG-C -311 TY1CL8STAGGG-C-311 32-6 B107.44 TY2 A wood cutting hand TY2CL5 Chisel
5110005969343 TY1CL3 A wood https/ B107.410 CAT 44 TY2 102BC 16-904 1042 GGG-C-311 B107.44B107.44 TY2
CAT 44 TY2 046299 https/ B107.410 CAT 44 TY2 1046 B107.410 16-978 106BC 16-908 B107.44B107.44 TY2 GGG-C
5110001868167 001868167 B107.410 CAT 44 TY2 32-3 828-C3203 046300 GGG-C-311 TY1CL8STAGGG-C-311B107.44
Woodworking Butt Chisel 5110005858431 5110-00-585-8431Woodworking Butt Chisel5110005858431 005858431
B107.410 1048 B107.410 CAT 44 TY2 GNK 1048 80244 - General Services Administration (Active) Incomplete
Restrictions 5110-00-585-8431
5110-00-585-8431 is a Woodworking Butt Chisel that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5110-00-585-8431
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5110-00-585-8431
- US Army (A192)
- Effective Date:
- 1 Sep 2013
- US Coast Guard (C014)
- Effective Date:
- 1 Apr 1991
- US Air Force (FGGS)
- Effective Date:
- 1 Apr 1991
- NASA (G751)
- Effective Date:
- 1 Apr 1991
- NASA (G881)
- Effective Date:
- 1 Apr 1991
- US Marine Corps (MC14)
- Effective Date:
- 1 Apr 1991
- US Navy (N9QG)
- Effective Date:
- 1 Jan 2005
- Former MOE Rule:
- NIQG
- Supplementary Collaborators:
- GTJNHSHD
- Supplementary Receivers:
- JV
- Israel (YD01)
- Effective Date:
- 1 Aug 2016
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5110-00-585-8431
- Part Number
- Manufacturer
- Status
- B107.410
- Manufacturer
- 05047 - The American Society Of Mechanical (Active)
- Incomplete Reference
- Incomplete Reference
- 1048
- 72896 - Great Neck Saw Manufacturers Inc. (Obsolete)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- B107.410 CAT 44 TY2
- 80244 - General Services Administration (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- GNK 1048
- 00NS2 - Kipper Tool Company (Active)
- Secondary Buy
- Secondary Buy
- 108BC
- 0YDJ6 - W L Fuller Inc (Active)
- Secondary Buy
- Secondary Buy
- 16-910
- 1CV05 - The Stanley Works (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- GGG-C-311 TY1CL3
- 80244 - General Services Administration (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- GGG-C-311
- 81348 - Federal Specifications Promulgated (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- B107.44
- 05047 - The American Society Of Mechanical (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 108BC
- 71178 - Buck Bros (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 16-910
- 78525 - Stanley Tools Div Of Stanley Works (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- B107.44 TY2
- 80244 - General Services Administration (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- B107.410
- Y9991 - Malaysian Army (Active)
- NATO Reference
- NATO Reference
Datasheet 5110-00-585-8431
- Characteristic
- Specifications
- FIIG
- Specifications
- A533V0
- Blade Attachment Method [BGLW]
- Tang
- Blade Length [AEAE]
- 2.500 Inches Minimum
- Blade Width [AEAF]
- 1.500 Inches Nominal
- Handle Material [CYAS]
- Plastic
- Nondefinitive Spec/Std Data [ZZZT]
- 2 Type
- Specification/Standard Data [ZZZK]
- 05047-Asme B107.410/B107.44 Professional/Industrial Association Standard
- Striking End Type [BGLR]
- Steel Cap
Management Data 5110-00-585-8431
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Jan 2023
- Department of the Army (DA)
- EA
- Subscribe
- EA
- Feb 2022
- Department of the Air Force (DF)
- EA
- Subscribe
- EA
- Mar 2019
- Department of the Air Force (DF)
- EA
- Subscribe
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- US Marine Corps (DM)
- M
- 0
- Reversal Of Phrase Code Z 5110-00-720-4878
- 0
Army
- Materiel Category and Inventory Manager:
- E
- General Supplies (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9Q
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 2
- Non-Critical Repair Part
- Echelon Management:
- 02
- Operational Test:
- No Special Procedures
Similar Supply Items to 5110-00-585-8431
Freight Information 5110-00-585-8431
5110-00-585-8431 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 186620. A Sub NMFC of Z. It has a NMFC Description of TOOLS, NOI HAND OTHER THAN POWER. 5110-00-585-8431 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91810 which rates the freight between FCL and LCL. 5110-00-585-8431 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 5110-00-585-8431 is not classified as a special type of cargo when transported by water. 5110-00-585-8431 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
