4940-01-254-3531
Electric Gun Type Heater
4940012543531 012543531 AH-751
An electrically driven pistol-shaped device, normally hand-held, used to deliver hot air in excess of 100 degrees Celsius for drying, curing, forming, activating, softening, shrinking, and the like. The operating parts are usually housed in a protective inclosure. It may include air flow directing accessories and a means to hang the item. Excludes DRIER,ELECTRIC,HAND. View more Electric Heat Gun
May 2023
3
Marketplace 4940-01-254-3531
Request a Quotation from participating marketplace vendors
Related Documents 4940-01-254-3531 1+ Documents (More...)
/fsg-49/fsc-4940/us
Updated Every Day 4940-01-254-3531 RQST Updated Every Day 4940-01-254-3531 RQST NE Related Documents
Electric Gun Type Heater 4940012543531 AH-751 HEATER,GUN TYPE,ELECTRIC 10 EA NS Request Quotation Updated
Restrictions 4940-01-254-3531
4940-01-254-3531 is a Electric Gun Type Heater that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 4940-01-254-3531
- US Air Force (FGG4)
- Effective Date:
- 1 Sep 2000
- Former MOE Rule:
- FEE4
Approved Sources 4940-01-254-3531
- Part Number
- Manufacturer
- Status
- AH-751
- Manufacturer
- 83284 - Master Appliance Corporation (Active)
- Primary Buy
- Primary Buy
Datasheet 4940-01-254-3531
- Characteristic
- Specifications
- FIIG
- Specifications
- T276-D
- Frequency In Hertz [FREQ]
- 60.0
- Heating Element [BWQH]
- Included
- Housing Material [AJLF]
- Aluminum
- Overall Height [ABKW]
- 8.000 Inches Nominal
- Overall Length [ABHP]
- 12.000 Inches Nominal
- Overall Width [ABMK]
- 6.000 Inches Nominal
- Part Name Assigned By Controlling Agency [CXCY]
- Heater,Gun Type,Electric
- Wattage Rating [BDWW]
- 2160.00 Watts
- Switch Functional Positions [ANRK]
- Fan On-Off And Heating Element On-Off
- Switch Quantity [AZRK]
- 1
- Temp Rating [AZKQ]
- 750.0 Deg Fahrenheit Nominal
Management Data 4940-01-254-3531
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Jan 2014
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
Air Force
- Fund:
- LP
- Items initially authorized for local purchase
- Budget:
- *
- Need item review at the user level to determine the appropriate official budget code
- Aggregation Code:
- RH
- AUTO TEST EQUIPMENT/AUTO TEST SYSTEMS (ATE/ATS) (FSC RESIDUAL MMAC)
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - U
- Reparable. Condemn at Intermediate. AF Equipment Management System (AFEMS).
NATO Stock Numbers Related to 4940-01-254-3531
Freight Information 4940-01-254-3531
4940-01-254-3531 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 148000. A Sub NMFC of X. It has a NMFC Description of OUTFITS SHOPS MILITARY REPAIR. 4940-01-254-3531 is rated as class 110 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 73810 which rates the freight between FCL and LCL. 4940-01-254-3531 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 4940-01-254-3531 is not classified as a special type of cargo when transported by water. 4940-01-254-3531 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
