4920-01-044-5926
Hydraulic System Components Test Stand
4920010445926 010445926 9780-0074
A cabinetlike item usually with a front work area and consisting of the necessary instrumentation, integral hydraulic system and component mounting facilities. Designed to provide the hydraulic pressure for testing and/or calibrating hydraulic system components, such as valves, actuating cylinders, pressure regulators, accumulators, hose lines, hand and/or engine driven pumps and the like. May include facilities for filling and checking hydraulic systems for leakage and performance. See also PUMPING UNIT, HYDRAULIC. View more Hydraulic System Components Test Stand
September 2025
20
Marketplace 4920-01-044-5926
Request a Quotation from participating marketplace vendors
Related Documents 4920-01-044-5926 5+ Documents (More...)
/fsg-49/fsc-4920/us
Day 4920-01-044-5926 RQST Updated Every Day 4920-01-044-5926 RQST NE Related Documents 4920-01-044-5926
STAND,HYDRAULIC Day 4920-01-044-5926 RQST Updated Every Day 4920-01-044-5926 RQST NE Related Documents
Hydraulic System Components Test Stand Every Day 4920-01-044-5926 RQST NE Updated Every https//
Sources Datasheet Management https Components Test Stand www.nsnlookup.com /fsg-49/fsc-4920/us 4920-01-044-5926
System Components Test Stand CharacteristicSpecificationsFIIGA23900End Item Identification [AGAV] 4920-01-044-5926
-01-121-6863 RQST https CharacteristicSpecificationsFIIGA23900End Item Identification [AGAV] 4920-01-044-5926
Protection Cover 4920993148277 993148277 621-2427 4920-00-474-1005 4920-01-375-7472 4920-00-798-3577 4920-01-044-5926
Similar Supply Items to 4920-00-587-3951 4920-00-780-4601 4920-00-546-6566 4920-99-775-9670 4920-01-044-5926
/fsg-49/fsc-4920/us
Force (DF)LJInterchangeable With 4920-01-587-7138 https//www.nsnlookup.com /fsg-49/fsc-4920/us 4920-01-044-5926
System Components Test Stand CharacteristicSpecificationsFIIGA23900End Item Identification [AGAV] 4920-01-044-5926
Restrictions 4920-01-044-5926
IUID Required
4920-01-044-5926 is a Hydraulic System Components Test Stand that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a confirmed Commerce Control List Item (CCLI). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 4920-01-044-5926
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4920-01-044-5926
- US Air Force (FGG4)
- Effective Date:
- 1 Sep 2000
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 2008
- Turkey (ZW01)
- Effective Date:
- 1 Dec 1995
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 May 2007
Approved Sources 4920-01-044-5926
- Part Number
- Manufacturer
- Status
- 9780-0074
- Manufacturer
- 05172 - Aai Corporation (Replaced)
- Original Design
- Original Design
- 9780-0074
- 06659 - Testek Llc (Active)
- Advisory Reference
- Advisory Reference
Datasheet 4920-01-044-5926
- Characteristic
- Specifications
- FIIG
- Specifications
- T361-E
- Installation Design [AMQY]
- Portable
- Usage Design [ALBY]
- Aircraft Hydraulic System
- Pressure Rating [BGST]
- 6000.0 Pounds Per Square Inch Nominal
- Hydraulic Fluid Flow Rate [AAYJ]
- 60.0 Gallons Per Minute
- Engine Driven Hydraulic Pump Testing Design Feature [CGYK]
- Included
- Drive Type [AKCV]
- Electric Motor
- Flow Capacity Rating [CGYL]
- 30.0 Gallons Per Minute
- Maximum Operating Pressure [BJDW]
- 6000.0 Pounds Per Square Inch
- Maximum Speed Rating In Rpm [ATPR]
- 3600.0
- Power Source [ATJK]
- Electric Motor
- Horsepower Rating [ANCY]
- 40.0
- Current Type [ACDC]
- Ac
- Voltage In Volts [ELEC]
- 440.0
- Frequency In Hertz [FREQ]
- 60.0
- Phase [FAAZ]
- Three
- Pressure Manifold Subcircuit [CGYM]
- Included
- Subcircuit Quantity And Maximum Operating Pressure [CHGN]
- One 50 Psi
- Circuit Type [APBT]
- Booster Cylinder
- Circuit Pressure Rating [CHGP]
- 50.0 Pounds Per Square Inch Nominal
- Accumulator [AYJM]
- Not Included
- Filtering System [CHGQ]
- Included
- Pressure/Suction Hose [CHGR]
- Included
- Functional Classification [FCLS]
- Aa-9.2
- Functional Description [FTLD]
- Used To Test Acft Hydraulic Systems/Components Without Operating Acft Or Removing Components
- Reference Data And Literature [RDAL]
- T.O. 33D2-5-39-1
- Fsc Application Data [ZZZV]
- F-15 And F/Rf-4 Acft Age
Management Data 4920-01-044-5926
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Jan 2022
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Dec 2019
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Air Force (DF)
- L
- 3
- Reversal Of Phrase Code S 4920-00-903-2271
- 3
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 4920-00-361-4425
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 4920-00-152-2375
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 4920-00-925-7907
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 4920-01-587-7138
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 4920-01-615-3563
- J
Similar Supply Items to 4920-01-044-5926
Freight Information 4920-01-044-5926
4920-01-044-5926 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 147650. A Sub NMFC of X. It has a NMFC Description of OUTFITS MILITARY EQUIP FOR REPAIR. 4920-01-044-5926 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. 4920-01-044-5926 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 73790 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 4920-01-044-5926 is not classified as a special type of cargo when transported by water. 4920-01-044-5926 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4920-01-044-5926
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 125.0" H x 67.0" W x 68.0" L
- --
- --
- --
- Any Suitable Process
- 125.0" H x 67.0" W x 68.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Special Requirement
- Special Requirements – see Specific Instructions or Drawings provided
- Cushion, Anchor, Block or Brace as Required
- --
- --
- Special requirements
- Special Requirements – see Specific Instructions or Drawings provided
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
