4820-01-615-7640
Globe Valve
4820016157640 016157640 W01-2074B-02TYG .25IN
A valve with one inlet and one outlet connection with outlet flow parallel to inlet flow. The flow is controlled by the action of a stem which lifts the disk perpendicularly off the center axis of its seat. The stem is at a 90 degree (1.5708 radians) angle to axis of flow. Excludes VALVE, STOP-CHECK; COCK, SHUTOFF, SCREW STEM; and VALVE, SOLENOID. View more Globe Valve
November 2023
2
Marketplace 4820-01-615-7640
Request a Quotation from participating marketplace vendors
Related Documents 4820-01-615-7640 5+ Documents (More...)
Updated Every Day 4820-01-615-7640 RQST NE Related Documents 4820-01-615-7640 1+ Documents ( More...
1/2 NSN 4820-01-615-7640 (Identification) 2/2 - - 1.
Restrictions 4820-01-615-7640
4820-01-615-7640 is a Globe Valve that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 4820-01-615-7640
- US Navy (N9BC)
- Effective Date:
- 1 Jan 2013
- Supplementary Collaborators:
- HD
Approved Sources 4820-01-615-7640
- Part Number
- Manufacturer
- Status
- W01-2074B-02TYG .25IN
- Manufacturer
- 57574 - Velan Valve Corp. (Active)
- Primary Buy
- Primary Buy
- W01-2074B-02TYG .25IN
- 0RMF7 - Bright Lights Usa, Inc (Active)
- Secondary Buy
- Secondary Buy
- W01-2074B-02TYG .25IN
- 0AFH0 - J. N. Corporation (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 4820-01-615-7640
- Characteristic
- Specifications
- FIIG
- Specifications
- A046B0
- Material [MATT]
- Steel Uns K03504 Body
- Style Designator [STYL]
- Straight Thru
- Face To Face Distance [CWCF]
- 2.880 Inches
- Valve Size [CCFG]
- 0.250 Inches
- Flow Control Device [ADQU]
- Disk
- Media For Which Designed [MEDA]
- Fuel/Oil, Hydrocarbon Single Response
- Maximum Operating Pressure [CQGM]
- 800.0 Pounds Per Square Inch Single Response
- Valve Operation Method [AQLR]
- Manual
- Connection Type [AWLS]
- Unthreaded Internal Pipe All Ends
- Connection Style [AHNC]
- Socket All Ends
- Nominal Pipe Size Accommodated [AAAR]
- 0.250 Inches All Ends
- Bonnet Type [ADSR]
- Inside Screw
- Bonnet Attachment Method [ADST]
- Bolted
Weapon Systems (WSDC) 4820-01-615-7640
DLA Procurement Analysis 4820-01-615-7640
- Last Stock Position:
- 6 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 4820-01-615-7640
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 4820-01-615-7640
Freight Information 4820-01-615-7640
4820-01-615-7640 has freight characteristics managed by the Food and Drug Administration (FDA).It has a National Motor Freight Classification (NMFC) of 051080. A Sub NMFC of Z. It has a NMFC Description of FAUCETS,BIBCOCKS,GATES VALVES. 4820-01-615-7640 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 29300 which rates the freight between FCL and LCL. 4820-01-615-7640 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 594 for ocean manifesting and military sealift. 4820-01-615-7640 is not classified as a special type of cargo when transported by water. 4820-01-615-7640 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Procurement History 4820-01-615-7640 1 Records
Contracting Technical Data File (CTDF) 4820-01-615-7640 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
