4820-01-416-5978
Safety Relief Valve
4820014165978 014165978 MIL-DTL-24332 MIL-V-24332
A valve designed to automatically release excessive pressures. It is actuated by static pressure upstream of the valve and is used as a safety valve or relief valve, and may be set to close at a predetermined pressure. It is not designed for regulation of continuously fluctuating loads. It may be inline or cartridge (manifold) design. Excludes VALVE (1), RELIEF, PRESSURE AND TEMPERATURE. View more Safety Relief Valve
November 2023
3
Marketplace 4820-01-416-5978
Request a Quotation from participating marketplace vendors
Related Documents 4820-01-416-5978 5+ Documents (More...)
Photo 1/2 NSN 4820-01-416-5978 (Identification) 2/2 - - 1.
MIL-V-24332 VALVE,SAFETY RELIEF 8 EA NS Request Quotation FedMall Updated Every 15 Minutes 4820-01-416
//www.nsnlookup.com /fsg-48/fsc-4820/us 4820-01-416-5978 Safety Relief Valve 4820014165978 014165978
day Upgrade your Account Upgrade 4820-01-416-5978Safety Relief Valve4820014165978 014165978 MIL-DTL-24332
https//www.nsnlookup.com /fsg-48/fsc-4820/us 4820-01-416-5978 Safety Relief Valve 4820014165978 014165978
day Upgrade your Account Upgrade 4820-01-416-5978Safety Relief Valve4820014165978 014165978 MIL-DTL-
Relief Valve4820014165978 014165978 MIL-DTL-24332 MIL-V-24332 A valve designed to automatically release
GRADE B 1IN 65PSI A valve designed https/ MIL-V-24332 GRADE B 1IN 65PSI A valve designed MIL-V-
-01-416-5978 Safety Relief Valve 4820014165978 014165978 day Upgrade your Account Upgrade 4820-01-416
-5978Safety Relief Valve4820014165978 014165978 MIL-DTL-24332 MIL-V-24332 A valve designed to automatically
Restrictions 4820-01-416-5978
4820-01-416-5978 is a Safety Relief Valve that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 4820-01-416-5978
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4820-01-416-5978
- US Navy (N9BC)
- Effective Date:
- 1 Aug 2004
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- HD
Approved Sources 4820-01-416-5978
- Part Number
- Manufacturer
- Status
- MIL-DTL-24332
- Manufacturer
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- MIL-V-24332
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 4820-01-416-5978
- Characteristic
- Specifications
- FIIG
- Specifications
- A046B0
- Connection Style [AHNC]
- Socket With Brazing Ring Err-100
- Connection Type [AWLS]
- Unthreaded Internal Pipe All Ends
- Disk Loading Method [ADSU]
- Spring
- Flow Control Device [ADQU]
- Disk
- Material [MATT]
- Copper Alloy Body Or Nickel Alloy Body
- Material [MATT]
- Steel Corrosion Resisting Flow Control Device Or Nickel Alloy Flow Control Device
- Material [MATT]
- Steel Corrosion Resisting Seat Or Nickel Alloy Seat
- Material [MATT]
- Steel Corrosion Resisting Stem Or Nickel Alloy Stem Or Copper Alloy Stem
- Maximum Operating Pressure [CQGM]
- 150.0 Pounds Per Square Inch Single Response
- Nominal Pipe Size Accommodated [AAAR]
- 1.250 Inches All Ends
- Nondefinitive Spec/Std Data [ZZZT]
- B Grade
- Opening Pressure Setting [CSDC]
- 35.0 Pounds Per Square Inch
- Valve Discharge Flow Rate [ADSY]
- 25.0 Gallons Per Minute
- Valve Operation Method [AQLR]
- Automatic
- Style Designator [STYL]
- Angle
DLA Procurement Analysis 4820-01-416-5978
Management Data 4820-01-416-5978
Navy
- Cognizance:
- 3B
Similar Supply Items to 4820-01-416-5978
Freight Information 4820-01-416-5978
4820-01-416-5978 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 127220. A Sub NMFC of X. It has a NMFC Description of PRESSURE REG/RED/RELIEF VALVES NOI. 4820-01-416-5978 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 64490 which rates the freight between FCL and LCL. 4820-01-416-5978 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 594 for ocean manifesting and military sealift. 4820-01-416-5978 is not classified as a special type of cargo when transported by water. 4820-01-416-5978 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4820-01-416-5978
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- ASTM - D5118, Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
Contracting Technical Data File (CTDF) 4820-01-416-5978 October 2021
