4820-01-396-7799
Ball Valve
4820013967799 013967799 T-560-S6-R-66-FS-1/2IN
A multi-ported, nonlubricated valve designed to provide straight through flow or ability to direct a number of flows or pressure through a single valve. The flow is controlled by the rotation of a ported ball within a suitable ported seat(s). The ball is usually engaged by a stem. It is normally operated in an open or closed position. Excludes VALVE, CHECK. View more Ball Valve
May 2023
1
Marketplace 4820-01-396-7799
Request a Quotation from participating marketplace vendors
Related Documents 4820-01-396-7799 1+ Documents (More...)
Updated Every Day 4820-01-396-7799 RQST NE Related Documents 4820-01-396-7799 1+ Documents ( More...
) https//www.nsnlookup.com /fsg-48/fsc-4820/us 4820-01-396-7799 Ball Valve 4820013967799013967799 T-
Restrictions 4820-01-396-7799
4820-01-396-7799 is a Ball Valve that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 4820-01-396-7799
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 4820-01-396-7799
- US Navy (N9BC)
- Effective Date:
- 1 Aug 2004
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- GTHD
Approved Sources 4820-01-396-7799
- Part Number
- Manufacturer
- Status
- T-560-S6-R-66-FS-1/2IN
- Manufacturer
- 12168 - Nibco Inc (Active)
- Original Design
- Original Design
Datasheet 4820-01-396-7799
- Characteristic
- Specifications
- FIIG
- Specifications
- A046B0
- Material [MATT]
- Steel Corrosion Resisting Body
- Material [MATT]
- Steel Corrosion Resisting Flow Control Device
- Material [MATT]
- Plastic Polytetrafluoroethylene Seat
- Material [MATT]
- Steel Corrosion Resisting Stem
- Style Designator [STYL]
- Straight Thru
- Media For Which Designed [MEDA]
- Water-Oil-Gas Single Response
- Maximum Operating Pressure [CQGM]
- 2000.0 Pounds Per Square Inch Single Response
- Valve Operation Method [AQLR]
- Manual
- Connection Type [AWLS]
- Threaded Internal Pipe All Ends
- Connection Style [AHNC]
- Plain,Optional End(Pipe) All Ends
- Thread Series Designator [THSD]
- Npt All Ends
- Nominal Thread Size [CQJX]
- 0.500 Inches All Ends
- Thread Direction [AAJF]
- Right-Hand All Ends
DLA Procurement Analysis 4820-01-396-7799
Management Data 4820-01-396-7799
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
NATO Stock Numbers Related to 4820-01-396-7799
Freight Information 4820-01-396-7799
4820-01-396-7799 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051080. A Sub NMFC of Z. It has a NMFC Description of FAUCETS,BIBCOCKS,GATES VALVES. 4820-01-396-7799 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 29300 which rates the freight between FCL and LCL. 4820-01-396-7799 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 594 for ocean manifesting and military sealift. 4820-01-396-7799 is not classified as a special type of cargo when transported by water. 4820-01-396-7799 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 4820-01-396-7799
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Contracting Technical Data File (CTDF) 4820-01-396-7799 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
